Specifications
1, Laser rapid accurate welding
2,Low Cost, Better Quality
3,High Quality Laser welder
4,On time delivery
Hailei Manufacturer jewelry welding machine laser welder power 150W portable welding machine
Jewelry laser welding machine laser welder
Technology Parameter:
| Model | HL-W90 | HL-W150 |
| Maximum laser power | 90W |
150W |
| Laser wavelength | 1064nm | 1064nm |
| Laser welding depth | 0.1-3.3mm | 0.1-3.3mm |
| Pulse width | 0.5-20ms | 0.5-20ms |
| Size of light spot | 0.2-2mm | 0.2-2mm |
| Integrity power | 3KW | 3.5KW |
| Power supply | 220V/50Hz | 220V/50Hz |
| Repeating precision of work bench | ±0.01mm | ±0.01mm |
| Positioning precision of work bench | ±0.02mm | ±0.02mm |
| Laser type | Nd:YAG pulse | Nd:YAG pulse |
| Sighting positioning method | Semiconductor red light | Semiconductor red light |
| Cooling method | Water cooling | Water cooling |
| Voltage adjustment range | 100-400VDC | 100-400VDC |
| Peak pulse current | 400A | 400A |
INTRODUCTION:
This welder is specially developed for laser welding of jewelry used in perforating and spot welding of gold and silver jewelry. The laser spot welding is an important aspect of laser process technology application. The spot welding process is thermal conduction, i.e. the laser radiation heats the surface of work piece, and the surface heat diffuses to the interior through thermal conduction and melts the work piece by controlling the width, energy, peak power and repeating frequency of laser pulse to form specific molten pool. Because of its unique advantage, it is widely used in the process of gold and silver jewelry and welding of mini and small part.
Features:
1. One button operation: a key switch, simplifying the device boot process to facilitate the operator to use the cumbersome process.
2. SCM control and regulation: can store 50 groups of commonly used welding parameters for easy re-use.
3. Small size and light weight: reduced working space, easy to transport and move.
WORKING PRINCIPLE:
Laser spot welding is to use high energy laser pulse to heat the material in a tiny zone, the energy of laser radiation spread into the internal of the material by heat conduction, after the material melted, it will form a particular pool. Laser spot welding machine can weld the same or different material together.
OBSERVATION SYSTEM
Microscope magnification: 17.5X. + Word cursor center and the laserspot alignment (user adjustable). With high-speed electronic filter protection device to protect the operator eyes laser injury, relieve the operator eye fatigue,improve work efficiency, the installation of high-definition CCD surveillance systemsare available upon request.
CONTROLLING SYSTEM
An exclusive miniature industrial computer that contains the full functionality of an ordinary computer, its stability and anti-interference ability isfar better than the industry products (generally manufacturers are mostly the poor performance of low-cost single-chip control panel).
INSTALLATION CONDITIONS
220V50HZ alternating current, provide more than 30A current, voltage stability.
Environment: clean and no dust or little dust, temperature 55°F(13°C)to82°F(28°C),humidity:5%to75% no condensation.
Main consumables: xenon lamp, filter, pargon.
Jewelry laser welding effect
1.Express: DHL, TNT, UPS.
2.Air or Sea shipping,Cheap Price, but will take a little more time to reach you.
1.We are the professional manufacturer ,could supply you the most suitable welding machine for you products.
2.Give you a special customized system solutions with a competitive price.
3.Our welding machine has passed the ISO9001 test.
4.The good after-sales service would be offered for your any questions,for 1 year period.
5.The processed sample also can be delivered to you for testing before purchasing our machine.
Samples show room
1.Q: How can you guarantee that I have a good sale on this product?
A: Our products are professional, high quality and competitive price. We also offer professional technology and after-sale servies.
2. Q: So many sellers promise me best price and good qulity, so what prove, how can I trust one and who can I trust?
A: You know indeed, more often the reality is: The good supplier difficultly find the good buyer, and the sincere buyer hard look for the honest seller. So I am lucky guy if you are sincerely want to buy, because I am so easy to find the good buyer! I can't promise you cheapest price in global, but I can tell you I will offer you the best price to make you always WIN customers and comsumer! So let me know your target price and what you need for so that I can recommend the appropriate type for you, and I will do my utmost to offer you a perfect order to thank your trust!
Hailei Manufacturer jewelry welding machine laser welder power 150W portable welding machine
Are you interested in Jewelry laser welding machine? Pls don't hesitate to LEAVE MESSAGE to me.
