Specifications
Vibrating Feeder Machine1.Vibration, stable and reliable.
2. The trash rack adjustable gap to prevent material clogg
Zhengzhou Weilite Vibrating Feeder Machine
Zhengzhou Weilite Machinery Equipment Co., Ltd. is an import and export oriented enterprise. Our company produces large and medium-sized mining machinery, metallurgical equipment, building materials, cold pressure ball machines, Vibrating Feeders and Briquette & Ore Powder Ball Press Machines, etc.
Application Of Vibrating Feeder Machine
Vibrating Feeder Machine is a kind of linear direction feeding equipment. It features smooth vibrating, reliable operation, long service life and being suitable for feeding. They are widely used in mining, building-material, silicate and chemical industry in the crushing and screening plants. In the Sand-Stone production line, it can send materials to crusher evenly and continuously and at the same time, it can screen materials roughly. It can be used in these areas such as metallurgical industry, coal mining industry, mining-selecting, building, chemical and grinding industry, etc.
Vibrating Feeder Machine Work Principle
Vibrating Feeder Machine Features and Advantages
We take strickly measures to control the quality of the machines from the very begining we bought the row material to the end we sent the machine to you in confirming you the high quality products.
The structure of Vibrating Feeder: Vibrating feeder consists of vibrating frame, spring, vibrator, motor vibrating device and motor. The vibrator is made of two fixed eccentric shafts whose gears are jogged. When installation, the two gears must be jogged according to the sign. Through drive of the motor, the two eccentric shafts start rotating to produce a linear huge power which forces the feeder to vibrate. Through the vibration, The materials will slip and sling on the funnel, moving forward, when the materials pass the screening part, smaller parts will fall down, avoiding the further crushing, so screening purpose can be reached.
Technical Parameter Of Vibrating Feeder Machine
| Model | Funnel size(mm) | Maximum feeding granularity(mm) | Capacity(t/h) | Powder(kw) | Weight(kg) | Size(mm) |
| GZD-800x3000 | 850x3000 | 400 | 80-120 | 1.5x2 | 3895 | 3110x1800x1600 |
| GZD-960x3800 | 960x3800 | 500 | 120-210 | 2.2x2 | 3980 | 3850x1950x1630 |
| GZD-1100x4200 | 1100x4200 | 580 | 200-430 | 3.7x2 | 5570 | 4400x2050x1660 |
| GZD-1100x4900 | 1100x4900 | 580 | 280-500 | 5.5x2 | 6520 | 5200x2050x1700 |
| GZD-1300x5200 | 1300x4900 | 650 | 450-600 | 7.5x2 | 8200 | 5200x2350x1750 |
Our service
(1) Pre-sale Service:
Suitable-design products and resonable price will be supplied to you to meet your need. We can also offer experiment to test the equipment that the customer need.
(2) After-sale Service:
On the spot guidance for installation by our engineers, and the buyer is responsible for the expense. We have a perfect after-sales service system and team with professional.
Machine Installation
If you didn't get the suitable machine in this page , please email me you detailed requirement . We are the manufacturer with over 30 years working experience . We can assit you in this matter .Please don't hesitate to add my trademanager directly! I am always online for you
