Sand sieve - industrial sieving machine

Specifications

vibrating sieving machine
1)classified the raw material into different size
2)specifically design for stone/sand making proces

Industrial Sieving Machine - Sand Sieve

 Part One : Sieving Mechanism

Weilite design the vibrating sand sieving machine proving their exceptional reliability and high productivity and have become teh world standard in bulk material processing .Our inclined circular sand sieving machine are at the cutting edge of design , durability and performance and operate in the toughest environments throughout the world .



The sand sieving machine are design specifically for long life adn low maintenance with the unique vivrator the perfect partner.Sieves can be supplied with single ,double or triple shafted mechanisms that are either oil or greases lubricated depending on the application.

Part Two :Applications of  the Sand Sieving Machine

An extremely diverse range of materials can be handled using vibration equipment ,from powders to quarried rock , manufactured parts to large castings . In applying the correct design and manufacturing techniques , we can undertake a wide range of materials handling and processing applications .



Part Three : Main Parameters

Model	No. of Decks	sieving hole size	Feed-in size	Capacity	Motor Powder
2YK1235	2	5~120mm	≤400mm	60~210 t/h	5.5kw
2YK1854	2	5~200mm	≤400mm	200~450 t/h	18.5kw
3YK1545	3	5~150mm	≤400mm	110~385 t/h	15kw
3YK1860	3	5~200mm	≤400mm	250~600 t/h	22kw
3YK2160	3	6~200mm	≤400mm	300~750 t/h	37kw
3YK2460	3	6~200mm	≤400mm	400~850 t/h	45kw

Note :

Weilite design the sieving machine specifically for your application , so if the size of sieve is not listed please contact our international sales departmentfor more information . ( Tel : +86   371  86687769 )
