Low Cost Continuous Wood Rotary Drum Dryer

Low Cost Continuous Wood Rotary Drum Dryer thumbnail-1
Low Cost Continuous Wood Rotary Drum Dryer thumbnail-2
Low Cost Continuous Wood Rotary Drum Dryer thumbnail-3
Low Cost Continuous Wood Rotary Drum Dryer thumbnail-4
Low Cost Continuous Wood Rotary Drum Dryer thumbnail-5
Low Cost Continuous Wood Rotary Drum Dryer thumbnail-6
Low Cost Continuous Wood Rotary Drum Dryer photo-1
Low Cost Continuous Wood Rotary Drum Dryer photo-2
Low Cost Continuous Wood Rotary Drum Dryer photo-3
Low Cost Continuous Wood Rotary Drum Dryer photo-4
Low Cost Continuous Wood Rotary Drum Dryer photo-5
Low Cost Continuous Wood Rotary Drum Dryer photo-6
US$ 8,000 - 230,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drying Equipment
Place of Origin:
Henan, China
Contact Supplier Request Quote Chat Now
Zhengzhou Weilite Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Guangdong or other inland custom ports
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rotary Drying Equipment
Place of Origin Henan, China
Brand Name Weilite
Model Number ZTH series
Voltage 220v,380v or custom made
Power(W) 3-75kw
Dimension(L*W*H) 6000*600*600mm
Weight 2.9-104.9t
Certification ISO9001
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

wood rotary drum dryer





1.Wood Rotary Drum Dryer Introduction

Wood rotary drum dryer is mainly used for drying wet materials in building construction, metallurgy, chemical industries, and it can dry various materials with strong adaptability. Besides, rotary dryer is common drying device in cement plant with simple and reliable operation.

Low Cost Continuous Wood Rotary Drum DryerLow Cost Continuous Wood Rotary Drum Dryer

2)wood rotary drum dryer parts

Low Cost Continuous Wood Rotary Drum DryerLow Cost Continuous Wood Rotary Drum Dryer





2.Wood Rotary Drum Dryer Working Principle

Materials are sent to hopper of wood rotary drum dryer by belt conveyor or bucket elevator. The barrel is installed with slope to horizontal line. Materials enter the barrel from the higher side, and hot air enters the barrel from the lower side, materials and hot air mix together. Materials go to the lower side by gravity when the barrel rotates. Lifters on the inner side of barrel lift materials up and down to make materials and hot air mix completely.

Low Cost Continuous Wood Rotary Drum Dryer



3.Wood Rotary Drum Dryer Work Site Pictures

Low Cost Continuous Wood Rotary Drum DryerLow Cost Continuous Wood Rotary Drum DryerLow Cost Continuous Wood Rotary Drum Dryer

Low Cost Continuous Wood Rotary Drum Dryer



4.Main Technical Parameters Of Wood Rotary Drum Dryer

Model (mm)

Inclination (%)

Rotate speed (r/min)

Air inlet temperature (°C)

Power (KW)

Production capacity(t/h)

Weight (t)

Φ600x6000

3-5

3-8

≤700

3

0.5-1.5

2.9

Φ800x8000

3-5

3-8

≤700

4

0.8-2.0

3.5

Φ800x10000

3-5

3-8

≤700

4

0.8-2.5

4.5

Φ1000x10000

3-5

3-8

≤700

5.5

1.0-3.5

5.6

Φ1200x10000

3-5

3-8

≤700

7.5

1.8-5

14.5

Φ1200x12000

3-5

3-8

≤700

11

2-6

14.8

Φ1500x12000

3-5

2-6

≤800

15

3.5-9

17.8

Φ1800x12000

3-5

2-6

≤800

18

5-12

25

Φ2200x12000

3-5

1.5-6

≤800

18.5

6-15

33

Φ2200x18000

3-5

1.5-6

≤800

22

10-18

53.8

Φ2200x20000

3-5

1.5-6

≤800

30

12-20

56

Φ2400x20000

3-5

1.5-5

≤800

37

18-30

60

Φ3000x20000

3-5

1.5-5

≤800

55

25-35

78

Φ3000x25000

3-5

1.5-5

≤800

75

32-40

104.9

5.Packaging And Shipping For Wood Rotary Drum Dryer

Low Cost Continuous Wood Rotary Drum Dryer

Low Cost Continuous Wood Rotary Drum Dryer



6.Our Serices For Wood Rotary Drum Dryer


1)Pre-sale services: Enthusiasm

  • We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.

2)Sale services: Servant

  • Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.

3)After-sale services: Faithfulness

  • To establish long term friendship, we will regularly pay return visit to customers. Supplying technique, building design, instruction, installation and debugging for free.

4)We provide one-year warranty to make sure your machine runs consistently.

  • We always offering lifelong services and provide spare parts for a long term,and repair main parts under right using for free in one years.

7.Company Information-Zhengzhou Weilite Machinery

Zhengzhou Weilite Machinery Equipment Co.,Ltd. is a professional mining machine manufacturer, we also offers other machines such as crusher, ball mill, rotary dryer,belt dryer,briquette machine,mixer, etc.  Website: /

Low Cost Continuous Wood Rotary Drum Dryer



8.FAQ About Wood Rotary Drum Dryer



1.What's the raw material that can be dried?

  • Answer:Any kind of chips and lump material can be dried by our machine.

2.What kind of fuel can be used with the rotation drying machine?

  • Answer:Gas, Diesel, Coal, Wood and other solid fuels.

3.What's the drying type of your dryer?

  • Answer:Hot Air Drying Type.

4.Is the belt speed adjustable?

  • Answer:Yes.

5.Can we adjust the drying temperature?

  • Answer:Yes, we can adjust the drying temperature by adjusting the hot air inlet volume.
