Specifications
wall drilling machine1. Dept:200m
2. diameter:300mm
3. truck mounted
wall drilling machine
HFT-200 wall drilling machine
Item |
Unit |
Parameter |
||
structure |
rotary |
|||
power |
kw |
15 |
||
working state overall dimension |
length |
mm |
5995 |
|
width |
mm |
2060 |
||
height |
mm |
7500 |
||
structure weight |
kg |
1500 |
||
drilling depth |
m |
200 |
||
hole diameter |
mm |
75-300 |
||
driving lever |
mm |
53/59x4000 |
||
drill rod |
mm |
50 |
||
drill bit |
mm |
75-300 |
||
vertical shaft speed |
r/min |
64,128,287,557 |
||
winch |
roller diameter |
mm |
140 |
|
winding speed of single cord |
m/s |
0.12,0.22,0.49,0.95 |
||
lifting power of single cord |
kN |
24 |
||
content of roller |
m |
35 |
||
steel wire diameter |
mm |
13 |
||
drill tower |
rated load |
t |
5 |
|
effective height |
m |
6 |
||
tower leg specification |
mm |
160X120X6 |
||
faucet |
max lifting power |
kN |
50 |
|
rubber tube diameter |
mm |
50 |
||
mud pump |
model |
BW160 |
||
displacement |
L/min |
160 |
||
working pressure |
Mpa |
1.3 |
||
Reciprocating frequency |
number/min |
165 |
||
truck |
model |
ZB1043LSDS |
||
engine type/power |
LN4D27E3/66KW |
|||
seat |
3+3 |
|||
