Trailer Type Soil Sampling Machine HF200 for SPT

Trailer Type Soil Sampling Machine HF200 for SPT thumbnail-1
Trailer Type Soil Sampling Machine HF200 for SPT photo-1
US$ 8,500 - 15,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Zhengzhou Hanfa Prospecting Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rotary Drilling Rig
Power Type Diesel
Place of Origin Henan, China
Brand Name Hanfa
Model Number HF200
Usage Water Well
Certification ISO9001
Warranty 12monthes
After-sales Service Provided Engineers available to service machinery overseas

Specifications

soil sampling machine
1.trailer type,easy to move
2.diesel engine/electric motor
3.multi-functional
4.hydraulic feeding

trailer type hydaulic drilling rig HF200 for SPT, soil sampling





I.Introduction of soil sampling machine HF200 for SPT


>it can drill Max200m depth,Max 500mm drill diameter



2>it equip different drill bits to drill different stratum,such as sand,soil,clay,hard rock etc,high efficiency

3>Hydraulic system control and trailer type ,easy to operate and move,saving labor force

4>it can be used for drilling water well,geothermy well,soil sampling or mining sampling,geological prospecting etc,wide application

5>national inspection-free product,quality guarantee,it can be used at least 10 yrs without full repair;as well as we offer you one-year quality warranty of main machine

trailer type soil sampling machine HF200 for SPT



II. Technical parameter of soil sampling machine HF200 for SPT



Main machine technical parameter

Drilling depth

200m

Drlling diameter

300mm

End diameter

75mm

Drilling pipe diameter

50mm

Drilling angle

90°~75°

Drilling weight(no include power)

975kg

Unity machine dimesions

2.75×0.95×1.6m

Spindle

Spindle speed

64,128,287,557r/min

Spindle stroke

 450mm

Hoist

Max.single line hoisting capacity

2400kg

Reel lifting speed

17,35,75,151r/min

Reel diameter

140mm

Wirerope diameter

13mm

Wirerop cubic measure

35m

Hug floodgate diameter

260mm

Hug floodgate belt width

70mm

Distance between drill and hole

400mm

Power

Diesel engine

s1105 Model, 22HP

Electric Motor

Y160M—4 ,15kw 1440r/min

Mud pump

Type

Horizontal single urn twin-action

Displacement

170L/min

Maximum pressure

3.0Mpa

Work pressure

1.5Mpa

Water inlet caliber

40mm

Water to exit caliber

30mm

Triangle conveyer belt

B1728mm

Hydraulic pump

specification

CBT—F—314

Triangle conveyer belt

B1100×1

Useful

Geology general check exploration,Earth physics exploration,Road and high layer building ground survey,water Well,Blast opening etc drilling engineering





 III. Project case of soil sampling machine for SPT trailer type soil sampling machine HF200 for SPTtrailer type soil sampling machine HF200 for SPT



About us



trailer type soil sampling machine HF200 for SPTtrailer type soil sampling machine HF200 for SPT
