Product Details
Place of Origin: | Henan, China | Brand Name: | HF | Model Number: | BW200 |
Theory: | Mixed Flow Pump | Structure: | Piston Pump | Usage: | Water |
Power: | Hydraulic | Standard or Nonstandard: | Standard | Fuel: | Diesel |
Pressure: | High Pressure | Application: | Sewage |
Product Description
Specifications
BW200 mud pump for 200m depth water well projectCapacity:200L/min
Since our establishment in 2004, we have been devoting ourselves to researching and developing easy-operation, highly-efficient and large-capacity drilling rigs.
Designed for multiple functions,our HF series water well/core drilling rigs are designed for geological exploration, water well drilling, soil sampling, core sampling(normal coring and wireline coring), pile drilling, etc.
Mud mixing pump
1.model:BW160,BW200,BW250
2.diesel engine for power,easy to operate
3.superior quality,light weight
4.ISO
BW200 mud pump
BW-200 mud pump is horizontal double-acting reciprocating duplex piston pump.It is mainly used for feeding flushing fluid to feel drilling in core drilling process. It is lightweight,compact and is more suitable used in geological prospect.
To meet diamond drilling,BW-200 mud pump is fixed two-kind-diameter cylinder liner Φ80mm and Φ65mm,When the hole depth is 600m,we can use cylinder liner of Φ80mm,When the hole depth is 1000m,we use cylinder liner of Φ65mm.
Style | Horizontal |
Type | Double-acting |
Number of cylinder | Two |
Cylinder liner diameter (mm) | 80 65 |
Stroke(mm) | 85 |
Reciprocate number (number/min) | 145 |
Displacement(L/min) | 200 125 |
Pressure(MPa) | 4 6 |
Speed(r/min) | 530 |
Pitch of belt pulley(mm) | 385 |
Belt pulley | B type,five solts |
Power(as per client's request) | 295 type-diesel or motor |
Suction pipe diameter(mm) | 65 |
Scupper pipe diameter(mm) | 37 |
Dimensions(L×W×H,mm) | 1050*630*820 |
Weight(kg) | 300 |
1.Are you trading company or manufacturer?
We are professional manufacturer, and our factory mainly produce water well drilling rig, core drilling rig, DTH drilling rig, piling rig, etc. Our products have been exported to more than 50 countries of Asia, South America, Africa, and get a good reputation in the world.
2.Are your products qualified?
Yes, our products all have gained ISO certificate,and we have specialized quality inspection department for checking every machine before leaving our factory.
3.How about your machine quality?
All of our machines hold the ISO, QC and TUV certificate, and each set of machine must pass a great number of strict testing in order to offer the best quality to our customers.
4.Do you have after service?
Yes, we have special service team which will offer you professional guidance. If you need, we can send our engineer to your work site and provide the training for your staff.
5.What about the quality warranty?
We offer one-year quality warranty for machines' main body.
6.How long can you deliver the machine?
Generally, we can deliver the machine in 7 days.
