Home > Manufacturing & Processing Machinery > Drilling Rig > Mine Drilling Rig > HF-400L Multifunctional Drilling Rig, DTH Drilling Tools

HF-400L Multifunctional Drilling Rig, DTH Drilling Tools

Name: HF-400L Multifunctional Drilling Rig, DTH Drilling Tools
Brand: HF DTH drilling tools
SKU: 101796495
Availability: InStock

HF-400L Multifunctional Drilling Rig, DTH Drilling Tools thumbnail-1

HF-400L Multifunctional Drilling Rig, DTH Drilling Tools photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Rotary Drilling Rig

Power Type:

Diesel

Contact Supplier Request Quote Chat Now

Zhengzhou Hanfa Prospecting Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Rotary Drilling Rig

Power Type Diesel

Place of Origin Henan, China

Brand Name HF DTH drilling tools

Model Number HF-400L DTH drilling tools

Usage Water Well

Voltage 220V/380V

Power(W) 22kw

Dimension(L*W*H) 9400*2100*3200MM

Certification ISO9001

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

HF-400L multifunctional drilling rig, DTH drilling tools

HF-400L multifunctional drilling is a kind of medium, high efficiency, novel multifunctional hydraulic crawler rig, the rig is widely used in drilling wells, gas wells and other large drilling engineering construction, and can also be suitable for mine rescue rig, mining blasting hole, foundation pile hole construction, the unique design of hydraulic drilling rig, superior in large imported drilling rigs.

The rig is a unique patented products: top drive rotary power head and a hydraulic rotary disk rotating mechanism, hydraulic motors, hydraulic winch chain propulsion for deep hole drilling in institutions and mast. New drilling technology, the drilling machine with cone drilling, mud reverse circulation drilling technology, compressed air DTH hammer drilling technology, can finish cover layer, sand gravel, sand, rock layer stratum, large diameter deep hole construction. The drill, drill pipe rack lift unloading, leveling supporting legs, lifting, walking and other auxiliary movement by the hydraulic system, not only can improve the working efficiency, and reduces the labor intensity of operators.

Characteristics >>

* Guide lane matches with roller skate, it can reduce the sliding resistance,and also reduce friction and improvethe lifetime of extension guide.

* Hydraulic power head and a hydraulic rotary disc motor chain, drilling and hydraulic winch binding, new drilling method, reasonable power matching.

* Set covering layer, stratum two kinds of method in one construction drill

* Travelling to tracked self-propelled structure, optional6x6heavy truck to car type well drilling.

* The rig is very convenient with air compressor and DTH hammer, using compressed air DTH hammer drilling technology, complete the bedrock drilling operation.

* The rig is equipped with patent technology hydraulic rotary disk, mud pump, hydraulic winch, the mud can be completed normal circulation drilling technology.

* Drill carriage slipway and roller skate matching,Namely, reduce sliding resistance, and reduce the slide wear. To extend the service life.

* Two-speed hydraulic regulation is used in rotary,trust,lifting,shall make drilling specification more match with well working situation.

* Hydraulic system equipped with separate air-cooled hydraulic oil cooler,and can optional install water cooler to ensure hydraulic system keep continuous and efficient operation under the high-temperature weather conditions of different regions.
* Four strengthened hydraulic jacks can become selfloading system, to ensure rotation easy and save lifting costs.

Specifications:

Kw	Engine power	160
M	Max.drilling depth	400
Mm	Borehole diameter	Rock layer200-350,soil layer500-1000
Mpa	Working air pressure	1.05-2.46
m3/min	The total gas consumption	16-30
m/h	Drilling efficiency	10-25
m	Length of drill rod	6
mm	Drill pipe diameter	108
mm	The driven rod	108*108
KN	Axial pressure	200
KN	Lifting force	200
KN	Hydraulic hoist	200
m/min	Slow down,slow speed	9.2
m/min	Rise fast,fast forward speed	50
Nm	Power head of rotary torque	13000
Nm	Lower rotary hydraulic turntable	40000
r.p.m	Rotary speed	0-50,0-100
L/min	Hydraulic mud pump	400
KW	Equipped with generators	22
Km/h	Walking speed	3
°	Climbing ability	20
KN	Host weight	14500
mm	Mainframe exterior size	940021003200
