Crawler Type HF110Y Down the Hole Drilling Rig
US$ 19,950 - 25,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Your Best Choice!!!HFY90 Portable Airdraulic DTH Drilling RigUS$ 4,050 - 5,450MOQ: 1 Set -
HFY90 Portable Air & Hydraulic DTH Drilling RigUS$ 4,050 - 5,450MOQ: 1 Set
-
Hot Sale in South America, Durable HF300Y Underground Water Drilling MachineUS$ 100,000 - 300,000MOQ: 1 Set
-
Small Volume, Light Weight HF-15 Core Sampling Drilling RigUS$ 6,050 - 7,260MOQ: 1 Set
-
Small Volume, Light Weight HF-15 Gold Core Drilling RigUS$ 6,050 - 7,260MOQ: 1 Set
Condition
New
Type
Rotary Drilling Rig
Power Type
Diesel
Place of Origin
Henan, China
Brand Name
HF Crawler type hole drilling rig
Model Number
HF110Y Crawler type hole drilling rig
Usage
Other, blasting hole
Voltage
220V/380V
Power(W)
38KW
Weight
4000kg
Certification
ISO CE
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
Hot selling !!! HF110Y crawler blasting hole drilling rig
HF110Y crawler drill is designed with durable quality, less air consumption, wide adaptation, powerful grade ability.
it can qualify its customers’ work for blast hole or reinforcement hole whatever in surface mining , water electric building, defense works, traffic constructions, tunnel exploration long hole and so on by its widely drilling degree, less oil and air consumption, faster digging rate(15-25 m/h , f = 8-12).
Powerful grade ability and convenient move without electricity. It can finish more than 300,000 M3/a.( 8 hours one day)
Hole diameter |
80-120mm |
Hole depth |
Down 30m horizontal 40m |
Boom swing |
45° each side |
Boom dump |
0-45 from level |
Mast swing |
Level turn left 40°; turn right 35° |
Mast dump |
0-100° at level |
Compensate stroke |
1080mm |
Highest level hole height |
700-3100mm |
Air pressure |
0.7-1.8Mpa |
Air consumption |
8-13 m3/min |
Grade ability |
20° |
Move speed |
0.8-2km/h |
Feed length |
3m |
Draw force |
20KN |
Pure drill rate |
15-25m/h(14bar; f=8-12) |
Power |
38KW |
Total weight |
4000kg |
