Specifications
HFY90 mining drilling rig1,simple structure
2,hydraulic motor drive ,big torque
3,for mining ,blasthole drill
New Designed ! Most portable HFY90 Air & Hydraulic mining drilling rig
1. Application of HF series mining drilling rig
Since our establishment in 2004, we have been devoting ourselves to researching and developing easy-operation, highly-efficient and large-capacity drilling rigs.
Designed for multiple functions,our HF series water well/core drilling rigs are designed for geological exploration, water well drilling, soil sampling, core sampling(normal coring and wireline coring), pile drilling, etc.
2. technical parameters about mining drilling rig
I. Features and Advantages
HFY90 portable air& hydraulic mining drilling rig is one new designed,high efficiency,wide applicability open-air rock drilling equipment,mainly used for small and medium mine,road construction, defense,water conservancy.stone work etc.blasting drilling.
This machine is simple structure,easy to operate hydraulic motor drive,big rotary torque Adopt oil cylinder propelling,strong lifting capacity Light weight and small volume,conveient to transport.
2. The technical parameters
Model |
HFY90 |
Rock stratum |
f=8~16 |
Drilling diameter |
80~130mm |
Drilling depth |
20m |
Push length |
1m |
Max propulsion |
4.5KN |
Max. lifting ability |
15KN |
Work Air pressure |
0.5~0.7Mpa |
Air comsumption |
7m3/min |
Rotating speed(no load) |
110~160r/min |
Weight |
Drilling rig:240KG Hydraulic power unti:300KG Additional weight:450KG |
,
3,Designs of HF series mining drilling rig for sale
Innovation is the key to our success: During these years, we continually make new designs on our products to
make them easier for clients to use.
Hydraulic chuck: It is designed to save the trouble from ball chuck.
Slide: It is designed to move the machine backward or forward when you need to lift/change the drill rod or adjust
the drilling position.
Trailer: 2-wheel, 4-wheel, 6-wheel. It is designed to move the drilling rig with tractors or such pulling devices.
Truck mounted: Easy to move and operate, they are also with hydraulic systems.
Crawler: Self-propelled, able to clime, suitable for complex terrains.
Hydraulic system: Tower and support. It is designed to decrease labor cost; two men are more than enough
to operate the drilling rig with hydraulic system.
Digital control: Multiple data display, easy controlling and monitoring, very convenient and efficient for
geological study.
4. Production ability( mining drilling rig for sale)
We have more than 50 sets of processing equipment to ensure the quality of our product, which has proved worthy by our client’s recognition. And these equipments ensure large production capacity and adequate stock.
We have all the small models in stock all year long and the bigger ones ready within 15-30 days.
5. Customers( mining drilling rig for sale)
With all the effort put in, we have successfully marketed our products to almost every corner of the world. Here are the pictures of our clients’ visits and our clients’ on-the-site operation.
6. Packing( mining drilling rig for sale)
To protect drilling rigs during sea transportation, we give them proper packing.
HF130, HF80,HF150E,HF150,HF200,HF30: Wooden case
HF-3,HF-4,HFDX-6.HF-8,HFT200,HFT350B: Plastic woven bag
Spare parts: Wooden case or plastic woven bag
HFT-200, HFT-3: Nude, main machine in plastic woven bag.
7. Quality guarantee( mining drilling rig for sale )
Our products has been authorized and certified by TUV and ISO9001:2008. We guarantee the quality of the machines for one year after the trial run (excluding the wearing parts), but not exceeding 15 months from the date on which machines leave the factory.
