HF200Y multifunctional well drilling rig, caterpillar band water well drilling rig1.Water well drilling rig
2.Borehole rig
HF200Y multi-function water/rock drill rig is a new-design light-weight, high efficiency mainly applied to drill drilling water Wells, agricultural irrigation Wells and other well, especially for the mountain area and rock stratum for water supply projects. The rig adopt new type hydraulic pressure technology, and match a complete set of hydraulic motor with high torque and large diameter cylinder turn of the hydraulic oil cylinder propulsion.
Technical and parameter
Whole machine weight (Kg) |
8500 |
|
Machine dimension (mm) |
5700x2300x2700 |
|
Move speed (Km/h) |
0~2.5 |
|
Diesel engine(DEUTZ) |
CA4DF2-140Z-5Q |
|
Motor parameter |
103Kw/2500 |
|
Ground distance(mm) |
245 |
|
Air DTH hammer |
DHD360(DHD380) |
|
grade ability(°) |
25 |
|
Drill depth(m) |
200 |
|
Air Working Pressure (MPa) |
1.05-2.46 |
|
Air consumption capacity (m3/min) |
16-30 |
|
Drill rod (mm) |
Φ76 |
|
Drill rod length (mm) |
3000 |
|
Drill hole (Drill bit) diameter (mm) |
Φ115-254 |
|
Driving force(N) |
50000 |
|
Lifting power (N) |
95000 |
|
Rotary speed(rpm) |
Low speed |
52 |
Speediness |
104 |
|
Rotary torque (N·m) |
4000 |
|
