water drilling rigs for sale HF-3, national free-inspection product
- 50 Set / Sets per Month
- Qingdao Shanghai Tianjin
- T/T
- China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
- 100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
- HY-50H Small Domestic Hydraulic Water Well Drilling Rig of China
- 50m Depth Core Drilling Rig Portable Diamond in Mountain
- TSP core bit, BQ NQ HQ PQ core drill bits, HWL, wireline core barrels, diamond coring bits, hard formation, deep hole rock core recovery
- 1.5M 3M inner tube assembly, wireline core barrels, head assembly, impregnated diamond drilling, hard formation coring, deep hole rock core recovery
Product Details
Condition: | New | Type: | Rotary Drilling Rig | Power Type: | Diesel |
Place of Origin: | Henan, China | Brand Name: | Hanfa | Model Number: | HF-3 |
Usage: | Other, core drilling | Certification: | ISO9001 | Warranty: | 12monthes |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
water drilling rigs for sale1.trailer chasis
2.diesel engine:can be used in area without electricity
3.multifunction
4.I
Best-selling Model in Africa! HF-3 water drilling rigs for sale,can drill 600m depth
1. To be equipped with hexagonal vertical shaft and hexagonal drive drilling rod, with strong rigidity and big transfer torque.
2. The entire machine is featured by strong adaptability, high motive power, low cost and broad compatibility.
3. To be provided with hydraulic control pressure feed mechanism for the purpose of improvement of construction efficiency.
4. To use hydraulic control well head displacement mechanism for enlargement of initial hole diameter
1,Are you trading company or manufacturer?
We are professional manufacturer, our factory mainly produce water well drilling rig, core drilling rig, DTH drilling rig, piling rig, etc. Our products have exported to more than 50 countries of Asia, South America, Africa, win a good reputation in the world.
2,Are your products qualified?
Yes, our products all have passed ISO certificate, we have specialized quality inspection department for checking every machine before leaving our factory.
3,how about your machine quality
our machine passed ISO ,QC,TUV etc certificate,each set machine before leaving factroy ,we will have strict testing ,to assure to offer the best quality to our customers
4,do you have after service
we have special service team ,will offer you professional guidance ,if you need ,we can send our engineer to your worksite for training
5,what’s the qaulity warranty
we offer one year quality warranty of main machine
6,how long you can deliver the machine
generally,we can deliver the machine in 7 days
7,Are you trading company or manufacturer?
We are professional manufacturer, our factory mainly produce water well drilling rig, core drilling rig, DTH drilling rig, piling rig, etc. Our products have exported to more than 50 countries of Asia, South America, Africa, win a good reputation in the world.
8,Are your products qualified?
Yes, our products all have passed ISO certificate, we have specialized quality inspection department for checking every machine before leaving our factory.
9,What is the max depth and the max diameter of holes?
Theoretically speaking, the 75mm to 300mm in max diameter and 600m in the max depth are available. Here please note that the real depth and diameter might be different as per your special local working strata
10,What is your mentioned “Multiple Functions” of this drill?
More drilling technology, normal and reverse circulations for both mud and air, mechanical unit and hydraulic unit for mask up-down, etc. If more requirement and questions for this drill rig, please contact us for more details.
Drilling depth | m | 300-600 |
Open hole caliber | mm | 300 |
End hole caliber | mm | 75 |
Drilling rod | mm | Φ60 |
Drilling angle |
| 90°-65° |
Spindle | ||
Spindle forward speed | r/min | 57-1024 |
Spindle reverse speed | r/min | 45-212 |
Spindle stroke | mm | 560 |
Spindle inner diameter | mm | 96 |
Spindle lifting capacity | KG | 6000 |
Hoist | ||
Single line lifting speed | m/s | 0.515 0.894 1.421 1.948 |
Hug floodgate belt width | mm | 90 |
Tightrope caliber | mm | 12.5 or 14 |
Hoist single line lifting capacity | KG | 3000 |
Reel caliber | mm | 200 |
Reel cubic measure | m | 30 |
Mud pump | ||
Horizontal double actuator | ||
Displacement | L/min | 200,125 |
Triangle conveyer belt type |
| B×5 |
Work pressure | Mpa | 4.6 |
Water inlet caliber | mm | 65 |
Water to exit caliber | mm | 37 |
Oil pump | ||
Duplex gear oil pump F532/F314 | ||
Front displacement,pressure |
| 32L/min 20Mpa |
Behind displacement,pressure |
| 14L/min 20Mpa |
Drilling rig Power | ||
Diesel engine | Hp | 395Kz 27HP |
Electric motor | KW | Y180L-4 22KW |
Usage: water well drilling, geological general investigation and exploration, rock sampling, boreholes, farm irrigation, road and tall building basic exploration, etc.
|
We have more than 50 sets of processing equipment to ensure the quality of our product, which has proved worthy by our client’s recognition. And these equipments ensure large production capacity and adequate stock.
We have all the small models in stock all year long and the bigger ones ready within 15-30 days.
With all the effort put in, we have successfully marketed our products to almost every corner of the world. Here are the pictures of our clients’ visits and our clients’ on-the-site operation.
To protect drilling rigs during sea transportation, we give them proper packing.
HF130, HF80,HF150E,HF150,HF200,HF30: Wooden case
HF-3,HF-4,HFDX-6.HF-8,HFT200,HFT350B: Plastic woven bag
Spare parts: Wooden case or plastic woven bag
HFT-200, HFT-3: Nude, main machine in plastic woven bag.
9. Quality guarantee(water well drilling rig for sale )
Our products has been authorized and certified by TUV and ISO9001:2008. We guarantee the quality of the machines for one year after the trial run (excluding the wearing parts), but not exceeding 15 months from the date on which machines leave the factory.
