Your best choice! HF30 sample drilling rig & rock drilling rig.
Application:
- HF-30 is one full hydraulic portable sampling drilling rig which is in combination fo the characteristics of kinds drilling rig ,it uses gasoine engine sa power,relying on hydraulic dribing rotary,cylinder pressure etc to meet a wide range of load changes,very reliable operation.According to the drfferent geology,it can choice diamond,alloy or steel drill bit for drilling .
- It can implement non stop machine to down the lever, very high efficiency,handle centralized,easy to operate,compast structure,samll volume,light weight ,easy to disintegrate and removal,suit for drilling in flatlands or mountain area
- The rig hsa reliable performance,core complete,convenient and flexible,ideal for field work,improve the efficency and reduce the sampling coasts,this rif already has reached the domestic advanced level
Description------
HF-30 protable drill rig is mainly used for geochemical exploration sampling and regional geological mapping ,shallow surface and underground tunnel veins exploration,geophysical source hole construction,geotechnical engineering etc drilling and sampling engineering.
-
HF-30 protable drill rig is mainly used for geochemical explorationg sampling and regional gelolgical mapping ,shallow surface and underground tunnel veins explorationg,geophysical source hole construction,geotechnical engineering etc drilling and sampling engineering.
Technical parameter:
Drilling way:high-speed rotary cutting
Cyclic medium:water,mud
Max depth:35m
Power head speed(r/min):300-1000
Pressure of hydraulic system(Mpa):14
Power head trip(mm):1100
Power (HP):27
Tower:triangular form,hight:1.6m
Total weight:200Kg
Single weight:50Kg
Full configuration
Item
Specification
Unit
Quantity
main machine
HF-30 (import gasoline engine)
set
1
protection joint
φ33 or 42
Pc
1
drilling rod
φ33 or 42
M
30
tratum core sampler
φ46 or 75
set
1
diamond bit
φ46 or 60
Pc
1
jump ring
φ28 or 42
Pc
1
soil double coring sampler
φ75
Set
1
alloy hollow drill
φ75-89
Pc
1
drag bit
φ60 or 75
Pc
1
pipe tongs
650
Pc
2
ork
Pc
2
clean water pump
BW20
Set
1
accessory
Set
1
Technical Parameter Diameter 46/60mm Depth 30m Speed of mainshaft 150/500/1200(rpm) Weight of the main machine 171kg Drilling frame form Single upright batter brace Feed-through form Chain, chain wheel Drilling frame feed-through route 1.2m Height of drilling frame 1.65m Proportion of hand wheel and gear 1:30 Max feed-through power 750kg
