Specifications
1.Strong transport capacity2. durable structure
3. limitless length
4..ISO 9001:2008
professional mining belt conveyor
belt conveyor description
It is widely used in mining ,metallurgy ,coal and other industries ,the belt conveyor can be used to transfer bulk materials or materiala in pieces ,according to different transgerring requirements ,the transferring system can be of only one belt conveyor or consists of several conveyors ,or combined with other transferring equipmens .the belt conveyoer can be installed hotizontally or aslope to meet the needs of different transferring requirements.
belt conveyor feature
Adopting high precision, hard with surface gears, its carrying capacity is high, long service life Gather together structure, cover an area of an area small, When light weight, small size, Especially vertical transmission structure form, more suitable for the coal mine underground mining &transport machinery in use.
belt conveyor usage
Belt conveyor with large transportation amount, simple structure, convenient maintenance, component standardization etc., which widely used in mining, metallurgy, coal, and other departments, used to transport loose material or as articles, based on the transmission process requirement, can single-user conveying.
belt conveyor parameters
Bell width |
Length(m)/power(kw) |
Speed(m/s) |
Capacity(t/h)
|
||
500 |
<=12/3 |
12-20/4-5.5 |
20-30/5.5-7.5 |
1.3-1.6 |
78-191 |
650 |
<=12/4 |
12-20/5.5 |
20-30/7.5-11 |
1.3-1.6 |
131-323 |
800 |
<=6/4 |
6-15/5.5 |
15-30/7.5-15 |
1.3-1.6 |
278-546 |
1000 |
<=10/5.5 |
10-20/7.5-11 |
20-40/11-22 |
1.3-2.0 |
435-853 |
1200 |
<=10/7.5 |
10-20/11 |
20-40/15-30 |
1.3-2.0 |
655-1284 |
1400 |
<=10/7.5 |
10-20/11 |
20-40/15-30 |
1.3-2.0 |
655-1284 |
1600 |
<=10/7.5 |
10-20/11 |
20-40/15-30 |
1.3-2.0 |
655-1284 |
Show the spare parts of ball mill
Zhengzhou Huahong Machinery&Equipment Co., Ltd is a famous manufacturer of mining and sandstone production equipment in China. The main products include mineral-processing equipment such as crusher, ball mill, magnetic separator, flotation machine, rotary kiln and sandstone production equipment such as vibrating screen, sand making machine.
The quality guarantee is 12 months after finishing the trial run of machines which has been shipped to the buyer side. If any part (excluding easily damaging parts) is found defective in quality within warranty period, we would like to replace it for free. After warranty, spare parts can be replaced based on favorable price.
Why choose us
1.We are real manufacture factory ( not dealer)
All machineries from Zhengzhou Huahong Mining Machinery Manufactory are made by ourselves, with lower price, good quality and assured full after service; So please buy machine from factory.
2. With senior engineers for research and development.
3. We’d like to recommend a suitable type for you and send you a best quotation.
4. If you are new for this business, we will help you.
