Specifications
1.Simple structure2.Little loss of sand and powder
3.High capacity
Sand cleaning machine introduction
The efficient sand washing machine of XS series is a kind of cleaning equipment of international advance level for sand and slag pellets, developed on the basis of introducing foreign outstanding technology of the same kind of products.
Sand cleaning machine application
Sand washing is widely used for cleaning materials in the following industries: Quarry, minerals, building materials,
transportation, chemical industry, water conservation and hydropower, cement mixture station and so on.
Sand cleaning machien operating principle
Sand Washing drives the impeller in the water groove to move like a circle transmitted by electric motor and decelerator, and then mixes, overturns, cleans and discharges the sand or slag pellets in the water groove.
Sand cleaning machine features
1. Sand washing is of simple structure. The bearing device of impeller drive is separated from water and materials with water,to avoid in a large degree that the bearings are damaged by being soaked with water, sand or some polluted things.
2. When it is used for cleaning sand in quarries, it has many advantages compared with the traditional spiral one.
3. There is little loss for medium-sized and fine sand and stone powder. The grade and the fineness of the sand for
construction after being washed can be up to the national standards, such as "sand for construction" and "cobble
and brokenstones for construction".
4. There are no other wearing parts except the screen mesh.
5. It features of long service life and few times for maintenance.
Technical data
| Model | XS 3200 |
| Capacity | 100-280 t/h |
| Return of sand | 15-40 t/h |
| Power | 11kw |
| Weight | 8800kg |
Looking forward to hearing from you and welcome to visit our factory!
