Specifications
Automatic double-head hydraulic uncoiler*High efficiency, high quality
*Steady running
*Full automation
*Easy operating
Automatic double-head hydraulic uncoiler
Coil car:
1) Structure:steel welded structure with four wheels for moving
2) Transmission power:2.2kw pinwheel cycloid motor
3) Lifting power:hydraulic oil cylinder Φ180×700mm.
4) Lifting stroke:700mm.
5) Max. capacity:25000Kg.
Double-head uncoiler:
1) Type:two sides moving, inner expanding
2) Expanding drum type:with three steps, oil cylinder drive taper slide for radial expanding
3) Specification of steps:Φ458~Φ508mm, Φ560~Φ610mm, Φ710~Φ760mm
4) Specification of expanding oil cylinder:Φ140×75mm
5) Moving power:hydraulic oil cylinder Φ125×900mm for driving
6) Steel coil centering:two holders axial moving (single and double)
7) Braking:pneumatic pressure regulating braking
8) Applicable steel coil width:600~1600mm.
9) Max. applicable outer diameter of steel coil:1800mm.
10) Max. applicable weight of steel coil:25000Kg.
