Wheat bucket elevator with reasonable price

Specifications

1. Good sealing, less pollution
2. Easy maintenance
3. Large lifting capacity
4 ISO certification, stable
5.factory price

 Wheat bucket elevator with reasonable price



1. Brief introduction of wheat bucket elevator

(1Bucket elevator has characteristics of large transport capacity, high elevation, stable operation and long working life.

(2The machine is applicable for conveying the powder, grain and small block materials, such as coal, cement, block, sand, clay and ore.

(3The bucket elevator is allowed to convey materials with high temperature(250c)when armed with special chain structure, and the elevating height can reach 40m.



2.Features of wheat bucket elevator

A.Obvious features like low power required, effective inflow feeding & guiding discharge.

B.It has vast range of application with almost no limitation for lifting material forms and properties. Materials like power, grain or big lump could be all applicable .Also its good sealing condition could effectively reduces the environmental pollution.

C.Excellent running reliability. Advanced design and processing method ensure the running reliability of the complete machine.

D.Long service life. The design of this machine ensures that the materials is seldom scattered while feeding and discharging, which reduces the mechanical wearing.



3.Features of wheat bucket elevator:

1. Large capacity. (~240 m3/h)

2. Small space on the floor.

3. Higher lifting height (~40 meters)

4. It takes belt or chain as traction device. So less wear parts, longer life.

5. Running stably. AC motor and reduction gears are as its driving device. Lowfailurerate. It can be also suitable for continuous working.

6. Environmental, no pollution. Low noise (68~76 dB), good sealing, no dust leakage, no dust pollution.



4.Main technical parameters of bucket elevator

Model	Lifting Capacity (m3/h)		Bucket-Speed (m/s)	Feeding   Size (mm)	Bucket Volume (L)		Bucket Spacing (mm)
	Zh	Sh			Zh	Sh
TH160	15.77	24.97	1.4	≤25	1.2	1.9	500
TH200	17.87	28.6	1.4	≤30	1.5	2.4	500
TH250	31.43	48.19	1.4	≤35	3.0	4.6	500
TH315	35	60	1.4	≤40	3.75	6	512
TH400	58	94	1.4	≤45	5.9	9.5	512
TH500	75	118	1.4	≤50	9.3	15	688
TH630	114	185	1.4	≤660	14.6	23.6	688

Note: If the type is not what you need, please contact us and more other types are available.

Also, we are pleasure to special design  for you according to your needs.











5.Structure chart of bucket elevator



The cetificates of our factory



About our company

1.Zhengzhou Huahong Machinery Equipment Co., Ltd. mainly produces iron selecting equipment,kinds of drederes, dredging equipment, sand washing and sand making equipment, gold panning equipment, magnetic separating, crusher and so on, there are more than hundred kinds of products.

2.We design produce various of products according to the customers requirement and geographical condition. It is a modern largescale mineral processing equipment manufacturer for research and development, engineering design, producing installation, commissioning and after sale service.

3.We attach the development of scientific research, and form strategic partnership with the major research institutions. And we had established good cooperation with Import and export trading company, established Shandong magnetic equipment Research Instituting.

4.Honesty and credit is our bussiness value , customer first.First-class quality and first-class service is the business life.



Foreign customers come to visit our factory









Skype: huahongmachine11
