VANCH Uhf Rfid Long Range Handheld Reader With Bluetooth
Feature:
1. Support Bluetooth,WIFI,GPRS,2G/3G/4G
2. Support 1D/2D barcode scanning function
3. The max reading distance is 7 meter
4. Support 8MP camera
5. Support built-in communication module
6. Android 4.4 Operating System
7.Support voice communication
8.Date will not be lost under the situation of power completely off
(such as remove the battery and the power converter)
Parameter description |
|
Model |
VH-770AT |
Smartphone Parameter | |
Processor |
MSM8926 quad core 1.2GHz |
Operating System |
Android 4.4 |
RAM |
1GB |
ROM |
4GB(support TF,max32G) |
Display Screen |
5 inch IPS screen, resolution 1280*720(DPI294), HD Dead-Zone Free, visible in the sun, Support more capacitive touch |
Wi-Fi(Standard) |
IEEE 802.11b/g |
GPRS(Optional) |
GPRS, EDGE , 4-band 900/1800,850/1900 |
GSM/WCDMA/TD-LTE(2G/3G/4G Optional) |
band 850/2100,Cat.8 HSDPA Cat.6 HSUPA |
Bluetooth(Optional/Standard) |
Bluetooth 4.0 |
GPS |
Support Assisted Global Positioning System (support many popular navigation) |
SIM card |
Micro SIM card |
Camera(Optional) |
Back camera 8MP with flash light |
RFID module parameter | |
Data Transmitting |
High speed USB 2.0 interface,3.5 stick interface for charging |
RFID module |
UHF(Standard) |
Barcode module |
1D(Optional),2D(Optional) |
Chargeable battery |
2350 lithium polymer battery, Standby time 21days, working time: over 3 hours |
Attachment |
lithium polymer battery,5V/1A charger,USB (Mini 5 pin) data line |
UHF parameter | |
Working frequency |
860MHz~960MHz(Standard) |
Protocol |
EPC C1 G2(ISO18000-6C) |
Reading distance |
Max 7m(associated with tags and antennas) |
Physical parameter | |
Weight |
720g (including the battery ) |
Dimension(mm) |
148 x 77.5 x 27 ± 2 mm |
Environment parameter | |
Working temperature |
-20℃~50℃ |
Storage Temperature |
-20℃~70℃ |
Storage humility |
10%~90%RH,no condensing |
Protection Grade |
IP65 |
Animal tracking, asset tracking, inventory checking,container management system etc.
- We accept Paypal, T/T , Western Union as payment method.
- We will be happy to Combine shipping for more than 1 item ship to the same address
- Please make the payment in 3-5 days after you place the order to arrange the production.
Not only for this, we did some other related projects as well, pls check the project pictures.
Welcome to contact me at mail beata at if you have any interest!
** Vanch Intelligent Technology Co.,Ltd. was established in 2005, one of the earliest UHF RFID products manufacture and application solutions supplier in China.
** As High-tech enterprise and software development &Design company, Vanch has a number of patents and copyright of software and hardware. RFID products passed CE certification and FCC, sold very well in Europe and America market.
** VANCH is membership of RFID Enterprise Alliance, RFID Standards Association and Internet of Things Association.
