Vanch VH-80 tire management UHF RFID handheld Reader
Features
1.Android 4.0/Win CE 6.0 Operating System for option;
2.External UHF antenna, reading distance up to 7 m;
3.4''capacitive TFT LCD screen, visible in sunshine;
4.Support 1D/2D barcode scan, camera and 3G/GPRS module;
5.Independent mould, high protection rate;
6.Standard extension Interface;
7.Drop test: 1.2 meters drop to concrete ground.
Specifications
Item Number |
VH-80 |
|
Smartphone Specification Parameter | ||
Screen |
4"TFT Color Touch Screen, Resolution:480×800;16Bit True Color, Visible in outdoor sunshine, adjustable backlight. |
|
Wi-Fi (Standard) |
Confirm To IEEE 802.11b/g/n |
|
GPRS (Optional) |
GPRS, EDGE , 4-band 900/1800,850/1900 |
|
Bluetooth (Standard) |
Bluetooth 2.0 |
|
WCDMA (3G, Optional) |
band 850/2100,Cat.8 HSDPA Cat.6 HSUPA |
|
GPS Navigation (Optional) |
Internal GPS Module and Antenna |
|
Infrared (Optional) |
Support |
|
Camera (Optional) |
VH-80-A Internal 8 MPx Camera, With Flash Light, Auto Focus |
VH-80-W Internal 2 MPx Camera, With Flash Light, Auto Focus |
RFID Module Specification Parameter | ||
Data Transportation |
USB 2.0 Interface;RS-232/RS485 Interface(Optional),1 DC_IN plug hole(DC5V),1 TF Card Slot,1 SIM Card Slot. |
|
RFID Module |
UHF (Standard) |
|
Bar Code Module |
1D (Optional), 2D (Optional) |
|
Battery |
3.7V 4000mAh Lithium Battery, Internal 3.7V 3600mAh Lithium Battery |
|
Accessory |
One Battery Charger, One USB Data Cable |
|
RFID Parameter | ||
UHF Module |
UHF Reading & Writing, Confirm to: European Standard ETSI EN 302208 American Standard FCC Part 15 Japanese Standard TELEC Chinese Standard CMII |
|
Protocol |
EPC C1 G2(ISO18000-6C) |
|
Reading Distance |
6m (Depends On Transmit Power, Tag Type and Environmental) |
|
Antenna |
Linear polarization antenna(4dbi, Standard);Transmit Power 16dBm~30dbm |
|
Physical Parameter | ||
Weight |
768g |
|
Size (mm) |
190×80×40mm(Main Body Size),2250mm×110mm×1750mm(Full Size, Including Antenna and Pistol Grip) |
|
Environmental Parameter | ||
Operating Temperature |
-20℃~55℃ |
|
Storage Temperature |
-20℃~70℃ |
|
Storage Humidity |
5%~95%RH (non-condensing) |
|
Sealing |
IP65 |
|
Shenzhen VANCH Intelligent Technology Co., Ltd. is the leading UHF RFID product manufacturer and application solution supplier in China.
