long distance uhf rfid terminal reader with demo software
1. Support bluetooth, WIFI GPRS/WCDMA and other communication method
2. Support 1D/2D barcode scanning
3. Protocol: EPC C1 GEN2/IS018000—6C Tag larger than 7 meters
4. Support 5 million pixel camera
5.Support infrared communication module
6: Android 4.22 O/S
Basic Parameters | |
Model |
VH-770AT |
Inside | |
OS |
Android 4.0 |
CPU |
MSM8926 1.2GHZ quad core |
RAM |
LPDDR2 1GB |
ROM |
EMMC 4GB |
Micro SD card |
Support 32GB Micro SD card |
Camera |
8MP with flash |
Audio |
Support the speech |
Outside | |
Dimension |
148mm*77.5mm*27mm |
Weight |
<720g(including battery) |
Physical Interface |
USB 2.0 interface to connect the computer |
|
Display Screen |
5”IPS Touch Screen 1280*720 resolution HD Dead-Zone Free Visible in the sun Support more capacitive touch |
Battery |
2350 mah lithium polymer battery Standby time: more than 150hours Working time: more than 4 hours Charging time < 4.5 hour Date will not be lost under the situation of power completely off (such as remove the battery and the power converter) |
Developing Environment | |
SDK |
Offer |
Software Demo |
Offer |
|
Developing Language |
C++/C#/VB.NET |
Working Environment | |
Operating Temperature |
-20℃~50℃ |
Storage Temperature |
-20℃~70℃ |
Relative Humidity |
10%~90%RH non-condensing |
Protection Grade |
IP65 (Waterproof, shockproof and Dustproof. Drop proof) |
Wireless Communications | |
WCDMA (Optional) |
3G Band 850/2100 |
GPRS (Standard) |
2G 4-Band 900/1800,850/1900 |
Bluetooth (Optional) |
Conform to the Bluetooth 4.0 |
Wi-Fi (Standard) |
Conform to the IEEE 802.11b/g |
GPS | |
GPS (optional) |
Channel: channel 12 Error range: < = 10 meters |
RFID Function | |
UHF RFID (Standard) | |
Work Frequency |
915MHz |
Frequency Range |
865-868MHz/ 902-928MHz |
Protocol |
EPC C1 GEN2 /ISO18000-6C |
Read Distance |
>7m (associated with tags and antenna) |
Write Distance |
>2m |
Barcode Function | |
1D barcode (Standard) | |
Scanning Engine |
SE955/N431X |
Readable Code |
Code39, Code93, Code128, Code bar, EAN-13, EAN-8, UPC-A, UPC-E, ITF14, UCC/EAN-128, ITF25, Matrix25, EAN-128, ISBN and so on |
2D barcode (Optional) | |
Scanning Engine |
Moto-SE4500/Honeywell-5180 |
Readable Code |
PDF417, MicroPDF417, Composite, RSS, TLC-39, Data matrix, QR code, Micro QR code, Aztec, Maxi Code; Postal Codes: US Post Net, US Planet, UK Postal, Australian Post etc. |
The Attachment | |
One charger | |
One Li-Poly battery | |
One USB data line | |
