Long distance Impinj R2000 UHF RFID fixed reader
Features
1.Shell adopt high strength die-casting aluminum, highlighting the product quality
2.Adopt high-performance Impinj UHF reader chip IndyR2000,the best Intensive reader mode,the maximum read speed and optimum read ranges.
3.ISO 18000-6C and ISO 18000-6B compatible.
4.Application: logistics supply chain,fixed asset management and library and archive management etc.
Specification |
|
Model |
VF-747 |
| |
Performance Index | |
Frequency range |
860-868MHZ,902-928MHZ(can be customized) |
Supported regions |
US, Canada and other regions following FCC Europe and other regions following ETSI EN 302 208 with & without LBT regulations Mainland China Japan Korea Malaysia Taiwan |
Frequency modulation |
FHSS or fixed-frequency, can be set by software |
RF output |
+10.0 to +30.5 dBm;50 ohm load. |
Peak inventory speed |
> 500 tags/sec |
Tag Buffer Size |
800 tags @ 96 bit EPC |
Tag RSSI |
Supported |
Antenna Detector |
Supported |
Ambient Temp Monitor |
Supported |
The number of antennas |
1 TNCantenna connector; 2 TNC antenna connector; 4 TNC antenna connectors for selections |
Communication interface |
10M/100MAdaptive Ethernet,RS232,RS485,Wiegand26/34 interface |
Communication rate |
Serial rate 9600~115200bps,RJ45 is 10Mbps |
Secure firmware upgrade |
The upgrade mechanism can be extended |
input / output (GPIO) |
2 inputs, 1 output |
Application software |
Supply API SDK and VC and VB, Java application routines |
Tag Operation Performance | |
Reading distance |
8dbi Antenna configuration, typical read range: 3 to 25 m (depends on tag) |
Protocol |
EPC global UHF Class 1 Gen 2 / ISO 18000-6C/ ISO18000-6B |
Maximum receiver sensitivity |
-82 dBm; Maximum return loss: 10 DBm |
Mechanical electrical performance | |
Dimension |
200 (L) * 200 (W) * 35 (H) mm |
RF Connector |
TNC |
Power |
With 220V AC input, the output of +12 V/3A DC power converter |
Weight |
<2KG |
Humidity |
5% to 95%, Non-condensing |
IP rating |
IEC IP51 |
Operating Temp. |
-20 ºC to +60 ºC |
Storage Temp. |
-40°C to 80°C |
1. You are manufacturer or trading company?
We are original equipment manufacturer in RFID UHF reader for over 10 years.
2. How is your QC?
We have strict QC process and all the products will be 100% testing before shipping.
3. What is your payment term?
100% payment should be paid before shipping.
4. What is your payment way?
T/T, Western Union,Paypal, MoneyGram
5. What is your warranty?
Wthin 1 year.
6. Can I get technical support from you?
Sure. Our sales are of all good knowledge in the field. Besides, we have a technical team behind to support.
If you wanna know more specific about our RFID products,Please contact us for free:
