Huawei AP5010 Series Access Point Wireless Indoor Acces Mini Usb Wireless Access Points Point
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Huawei
Model Number:
AP5010
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Huawei AP5010 Series Access Point Wireless Indoor Acces Wifi Mini Access PointNegotiableMOQ: 1 Piece -
Huawei AP5010 Series Long Range Access Point Wireless Indoor Acces Wifi 5.8ghz Access PointNegotiableMOQ: 1 Piece
-
Huawei AP5010 Series Long Range Access Point Wireless Indoor Acces Wifi 5.8ghz Access Point in Wall Access PointNegotiableMOQ: 1 Piece
-
Huawei AP5010 Series Long Range Access Point Wireless Indoor Acces Wifi 5.8ghz Access Point WifiNegotiableMOQ: 1 Piece
-
Huawei AP5010 Series Long Range Access Point Wireless Indoor Acces Wifi 5.8ghz Wall Mount Access PointNegotiableMOQ: 1 Piece
Place of Origin
Shanghai, China
Brand Name
Huawei
Model Number
AP5010
Huawei AP5010 Series Access Point
| mini usb wireless access point |
The AP5010 series includes AP5010DN-AGN and AP5010SN-GN, which have the same appearance, ports, and indicators.
The AP5010 series standard 11n access points use an elegant design and are recommended for use in buildings with a simple structure, a small size, a high density of users, and requires a high capacity, for example, small-scale conference rooms, bars, and entertainment areas. This series is available in two models: AP5010SN-GN and AP5010DN-AGN.
• 2×2MIMO (two spatial streams)
• Fit/Fat mode
• PoE or DC power supply
• Built-in antennas
• 17 dbm
Specifications
| Item | Description | |
|---|---|---|
| Technical specifications | Dimensions (H×W×D) | 50 mm×180 mm×180 mm |
| Weight | 0.4 kg | |
| System memory | 128 MB DDR2 32 MB flash memory |
|
| Power specifications | Power input | DC 12V±10% POE Power: -48V DC PoE function in compliance with IEEE 802.3af and 802.3at |
| Maximum power consumption | AP5010DN-AGN: 9.5 W AP5010SN-GN: 6.0 W NOTE:The maximum power consumption depends on local laws. |
|
| Environment parameters | Operating temperature | -10°C to +50°C |
| Storage temperature | -40°C to +70°C | |
| Humidity | 5% to 95% (non-condensing) | |
| Waterproof grade | IP31 | |
| Altitude | –60 m to 4000 m | |
Highly reliable wireless access
- AP5010DN-AGN: complies with IEEE 802.11a/b/g/n.
- AP5010SN-GN: complies with IEEE 802.11b/g/n.
- Supports 2 x 2 MIMO and provides a maximum rate of 300 Mbit/s.
- Supports Wi-Fi Multimedia (WMM) and priority mapping on the air interface and wired interface.
- Supports wired link integrity check.
- Supports load balancing.
- Supports roaming without service interruption in Fit AP mode.
- Supports AC dual-link backup and VRRP hot backup in Fit AP mode.
- Supports 11n beamforming.
- Uses the latest 802.11n chip to provide higher performance and wider coverage.
Comprehensive user access control capability
- Supports access control lists (ACLs) and implements user access control based on the user group policy.
- Provides fine-grained bandwidth management for each user.
- Supports user isolation policies.
- Supports unified authentication on the AC in Fit AP mode.
- Identifies the device type according to the organizationally unique identifier (OUI) in the MAC address, user agent (UA) information in an HTTP packet, and DHCP options in Fit AP mode.
- The RADIUS server delivers packet forwarding, security, and QoS policies according to the device type carried in the RADIUS authentication and accounting packets in Fit AP mode.
High security
- Open system authentication
- WEP authentication/encryption
- WPA/WPA2-PSK authentication and encryption
- WPA/WPA2-802.1x authentication and encryption
- WAPI authentication and encryption
- Supports wireless intrusion detection system (WIDS), including rogue AP and STA detection, attack detection, STA/AP blacklist and whitelist.
Flexible networking and environment adaptability
- Provides flexible networking capabilities and applies to various application scenarios. Mesh and WDS scenarios are supported only in Fit AP mode.
- Has strong environment adaptability. The AP can automatically select the transmission rates, channels, and transmit power to adapt to various radio environments and avoid interference in real time.
- Adjusts bandwidth allocation based on the user quantity and environment to improve user experience.
- Identifies interference sources such as bluetooth devices, microwave ovens, cordless phones, ZigBees, game controllers, 2.4 GHz/5 GHz wireless video and audio devices, and baby monitors in Fit AP mode and works with eSight to locate interference sources and display spectrums.
Simple device management and maintenance
- Automatically goes online and loads the configuration, and supports plug-and-play (PnP) in Fit AP mode.
- Supports batch upgrade.
- Allows real-time monitoring on the network management system (NMS) to facilitate remote configuration and fast fault location.
- Supports the Link Layer Discovery Protocol (LLDP) to implement automatic link discovery and obtain the network topology.
Deployment
The AP5010DN-AGN and AP5010SN-GN provide 802.11n wireless access networks for places with simple building structure, small size, dense users, and high capacity demands, such as small and medium enterprises and branches. The AP5010DN-AGN can be flexibly deployed and work in both fit AP and bridge mode.
The AP5010DN-AGN and AP5010SN-GN can work as a Fat AP or Fit AP and switch flexibly between the two working modes based on the network plan.
When the wireless network scale is small, customers need to purchase only AP products and set the APs to work as Fat APs. As the network scale expands, tens of or hundreds of APs exist on the network. To simplify network management, c
ustomers are advised to purchase ACs to perform centralized management on the APs and set the APs to work as Fit APs.
