Product Details
Place of Origin: | Shanghai, China | Brand Name: | Huawei | Model Number: | AP6310SN-GN |
Product Description
Huawei AP6310SN-GN Series Access Point
The AP6310SN-GN is an enhanced series indoor single-band Access Point (AP), which supports indoor distributed coverage. The AP6310SN-GN can be used together with the 2G/3G/CATV Signal System, and they share the 2G/3G/CATV indoor distributed system. The AP6310SN-GN is applicable to the indoor wide coverage scenario with signal attenuation and low user density.
The AP6310SN-GN is recommended on large-scale networks where users are distributed in a large area and an indoor distribution system is used, for example, office buildings, business buildings, hotels, airports, and bus stations. The AP6310SN-GN APs provide indoor wireless signal coverage in these scenarios
WLAN features
- AP6310SN-GN: complies with IEEE 802.11b/g/n.
- AP6310SN-GN: provides a maximum rate of 150 Mbit/s.
- Maximum ratio combining (MRC)
- Maximum-likelihood detection (MLD)
- Data unit aggregation, including A-MPDU (Tx/Rx) and A-MSDU (Rx only)
- Short GI in 20 MHz and 40 MHz modes
- Priority mapping and packet scheduling based on a Wi-Fi Multimedia (WMM) profile to implement priority-based data processing and forwarding
- Automatic and manual rate adjustment (the rate is adjusted automatically by default)
- WLAN channel management and channel rate adjustment
- Automatic channel scanning and interference avoidance
- Service set identifier (SSID) hiding
- Signal sustain technology (SST)
- Unscheduled automatic power save delivery (U-APSD)
- Control and Provisioning of Wireless Access Points (CAPWAP) in Fit AP mode
- Automatic login in Fit AP mode
Network features
- Compliance with IEEE 802.3u
- Auto-negotiation of the rate and duplex mode and automatic switchover between the Media Dependent Interface (MDI) and Media Dependent Interface Crossover (MDI-X)
- SSID-based VLAN assignment
- VLAN trunk on uplink Ethernet ports
- 4094 VLAN IDs (1-4094) and a maximum of 16 virtual APs (VAPs) for each radio
- AP control channel in tagged and untagged mode
- DHCP client, obtaining IP addresses through DHCP
- Tunnel data forwarding and direct data forwarding
- STA isolation in the same VLAN
- Access control lists (ACLs)
- Link Layer Discovery Protocol (LLDP)
- Uninterrupted service forwarding upon CAPWAP channel disconnection in Fit AP mode
- Unified authentication on the AC in Fit AP mode
- AC dual-link backup and VRRP hot backup in Fit AP mode
Specifications
Item | Description | |
---|---|---|
Technical specifications | Dimensions (H×W×D) | 35 mm×130 mm×150 mm |
Weight | 0.6 kg | |
System memory | 128 MB DDR2 32 MB flash memory | |
Power specifications | Power input | DC 12V±10% POE Power: -48V DC PoE function in compliance with IEEE 802.3af and 802.3at |
Maximum power consumption | 8.3 W NOTE:The maximum power consumption depends on local laws. | |
Environment parameters | Operating temperature | -10°C to +50°C |
Storage temperature | -40°C to +70°C | |
Humidity | 5% to 95% (non-condensing) | |
Waterproof grade | IP31 | |
Altitude | –60 m to 4000 m |
Radio Specifications
Item | Description | |||
---|---|---|---|---|
Radio connector type | N type (Female) | |||
Antenna type | depends on the type of antennas in the indoor antennas system. | |||
Maximum number of concurrent users | 128 | |||
Maximum transmit power | 27 dBm You can adjust the transmit power from the maximum transmit power by 20 dB, with a step of 1 dB. | |||
Maximum number of non-overlapping channels | 802.11b/g | |||
Channel Rate | 802.11b: 1, 2, 5.5, and 11 Mbit/s | |||
802.11g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/s | ||||
802.11n data rate (2.4 GHz) | ||||
GI2=800ns | GI=400ns | |||
20 MHz (Mbit/s) | 40 MHz (Mbit/s) | 20 MHz (Mbit/s) | 40 MHz (Mbit/s) | |
6.5 @ MCS10 | 13.5 @ MCS0 | 7.2 @ MCS0 | 15 @ MCS0 | |
13 @ MCS1 | 27 @ MCS1 | 14.4 @ MCS1 | 30 @ MCS1 | |
19.5 @ MCS2 | 40.5 @ MCS2 | 21.7 @ MCS2 | 45 @ MCS2 | |
26 @ MCS3 | 54 @ MCS3 | 28.9 @ MCS3 | 60 @ MCS3 | |
39 @ MCS4 | 81 @ MCS4 | 43.3 @ MCS4 | 90 @ MCS4 | |
52 @ MCS5 | 108 @ MCS5 | 57.8 @ MCS5 | 120 @ MCS5 | |
58.5 @ MCS6 | 121.5 @ MCS6 | 65 @ MCS6 | 135 @ MCS6 | |
65 @ MCS7 | 135 @ MCS7 | 72.2 @ MCS7 | 150 @ MCS7 | |
NOTE:Modulation coding scheme (MCS) index: determines the spatial flow quantity, modulation, coding rate, and data rate. | ||||
Receiver Sensitivity | 802.11b (CCK): | 802.11g (non-HT20): | ||
802.11n(HT20): | 802.11n(HT40): |
