Home > Electrical & Electronics > Telecommunication & Broadcasting > WiFi Products > Huawei AC6605 Wireless Access Controller

Huawei AC6605 Wireless Access Controller

Name: Huawei AC6605 Wireless Access Controller
Brand: Huawei
SKU: 101660775
Availability: InStock

Huawei AC6605 Wireless Access Controller thumbnail-1

Huawei AC6605 Wireless Access Controller photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

China

Brand Name:

Huawei

Model Number:

AC6605

Contact Supplier Request Quote Chat Now

Shanghai Chu Cheng Information Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin China

Brand Name Huawei

Model Number AC6605

Huawei AC6605 Wireless Access Controller

The Huawei AC6605-26-PWR access controller integrates 1000M Ethernet switch functionality for both wired and wireless access control. The AC6605-26-PWR offers users broad flexibility in configuring Access Points (APs). Used together with Huawei Premium Series Huawei APs, Enhanced Series Huawei APs and Standard Series Huawei APs, the AC6605-26-PWR delivers an enterprise grade networking solution for campus, industrial, and small- and medium-scale enterprise networks and extends hotspot coverage

Abundant Port Types

Uplink port :Two 10GE optical ports.
Service port: 24 GE ports, the last four are used with four optical ports as combo interfaces.
Maintenance port:One RJ45 maintenance serial port; One RJ45 maintenance Ethernet port ; One mini USB maintenance serial port.

Large Capacity, High Performance, Integrated Design

Integrated design: An AC can function as an access or aggregation device to provide wired access services and function as a management device to control STA access.
Large switching capacity: An AC device has twenty-four GE interfaces and two 10GE interfaces. It provides 128 Gbit/s switching capacity and 10 Gbit/s forwarding capacity.
PoE: The AC supports the PoE function and can provide the maximum power on 24 ports. This PoE capability can provide power to APs and other powered devices (PDs) connected to the AC unit.

Carrier-Class Reliability

The AC supports port backup based on the Link Aggregation Control Protocol (LACP) or Multiple Spanning Tree Protocol (MSTP).
The AC supports redundant AC/DC power supplies.
The AC supports hot swappable power supplies.
The AC supports 1+1 hot backup.

Easy-to-Install and Easy-to-Maintain

The AC6605 dimensions (width x depth x height) are 442 mm × 420 mm × 44.4 mm and the AC6605 can be installed in a standard IEC cabinet (19 inch).
Power supplies of AC are hot swappable, facilitating maintenance.
The built-in web system of AC allows local GUI-based management.
The AC can be managed by the eSight that provides various northbound interfaces.
The AC support the intra-board temperature probe, which monitors the operating environment of the AC in real time.

Energy Conservation

Low noise fans that can adjust the speed automatically are used, thus reducing noises in the system and power consumption of fans.
The chip switches to the power saving mode when no connected device is detected on a service interface, that is, the interface is idle.
It uses highly-integrated and energy-saving chips produced through advanced processing techniques. With the help of the intelligent device management system, the chips not only improve system performance but also greatly reduce power consumption of the entire system

System Configuration

Item	Specifications
Processor	Dominant frequency: 1 GHz
Switching capacity	128 Gbit/s
Packet forwarding capacity	10 Gbit/s
DDR memory	4 GB
Flash memory	256 MB

Physical Specifications

Item		Description
Dimensions (width x depth x height)		442 mm x 420 mm x 44.4 mm
Maximum power consumption		85 W
Weight		Net weight: 5.48 kg Fully configured with 150 W power supplies: 7.16 kg Fully configured with 500 W power supplies: 7.48 kg
Operating temperature		-5ºC to +50ºC
Relative humidity		5% RH to 95% RH, noncondensing
Operating altitude		150 W DC power supply: 0 m to 2000 m Others: 0 m to 3000 m
AC input voltage	Rated voltage	100 V AC to 240 V AC, 50/60 Hz
AC input voltage	Voltage range	90 V AC to 264 V AC, 47 Hz to 63 Hz
DC input voltage	Rated voltage	-48 V DC to -60 V DC
DC input voltage	Voltage range	-36 V DC to -72 V DC

Protocol and Management Capabilities

Parameter	Specifications
Number of managed APs	512
Number of access users	Entire device: 10K Single AP: a maximum of 256 (depending on the AP model)
Number of MAC address entries	16K
Number of VLANs	4K
Number of routing entries	10K
Number of ARP entries	8K
Number of multicast forwarding entries	4K
Number of DHCP IP address pools	128 IP address pools, each of which contains a maximum of 16K IP addresses
Number of local users	1000
Number of ACLs	8K
Number of ESSIDs	4K
User group management	128 user groups Each user group can reference a maximum of eight ACLs. Each user group can associate with a maximum of 128 ACL rules.

Wireless Networking Capabilities

Feature	Specifications
Networking between APs and ACs	APs and ACs can be connected through a Layer 2 or Layer 3 network. APs can be directly connected to an AC. APs are deployed on a private network, while ACs are deployed on the public network to implement NAT traversal. ACs can be used for Layer 2 bridge forwarding or Layer 3 routing.
Forwarding mode	Direct forwarding (distributed forwarding or local forwarding) Tunnel forwarding (centralized forwarding) Centralized authentication and distributed forwarding Before users are authenticated, tunnel forwarding is used. After users are authenticated, local forwarding is used.
Wireless networking mode	WDS bridging: Point-to-point (P2P) wireless bridging Point-to-multipoint (P2MP) wireless bridging Automatic topology detection and loop prevention (STP) Wireless mesh network Access authentication for mesh devices Mesh routing algorithm Go-online without configuration
AC discovery	An AP can obtain the AC6605-26-PWR's IP address in any of the following ways: Static configuration DHCP Option 43 DNS The AC6605-26-PWR uses DHCP to allocate IP addresses to APs. DHCP relay is supported. On a Layer 2 network, APs can discover the AC6605-26-PWR by sending broadcast or multicast CAPWAP packets.
CAPWAP tunnel	Centralized CAPWAP CAPWAP control tunnel and data tunnel (optional). CAPWAP tunnel forwarding and direct forwarding in an extended service set (ESS). Datagram Transport Layer Security (DTLS) encryption, which is enabled by default for the CAPWAP control tunnel Heartbeat detection and tunnel reconnection.
Active and standby ACs	Enables and disables the switchback function. Supports load balancing. Supports 1+1 hot backup.

Switching and forwarding features

Feature		Description
Ethernet features	Ethernet	Operating modes of full duplex, half duplex, and auto-negotiation Rates of an Ethernet interface: 10 Mbit/s, 100 Mbit/s, 1000 Mbit/s, and auto-negotiation Flow control on interfaces Jumbo frames Link aggregation Load balancing among links of a trunk Interface isolation and forwarding restriction Broadcast storm suppression
	VLAN	Access modes of access, trunk, hybrid, and Default VLAN
	MAC	Automatic learning and aging of MAC addresses Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses Interface-based MAC learning limiting
	ARP	Static and dynamic ARP entries ARP in a VLAN Aging of ARP entries
	LLDP	LLDP
Ethernet loop protection	MSTP	STP RSTP MSTP BPDU protection, root protection, and loop protection Partitioned STP
IPv4/IPv6 forwarding	IPv4 features	ARP and RARP ARP proxy Auto-detection
	Unicast routing features	Static route RIP-1 and RIP-2 OSPF BGP IS-IS Routing policies and policy-based routing URPF check DHCP client,server and relay DHCP snooping
	Multicast routing features	IGMPv1, IGMPv2, and IGMPv3 PIM-SM Multicast routing policies RPF
Device reliability	BFD	BFD
Layer 2 multicast features	Layer 2 multicast	IGMP snooping Prompt leave Multicast traffic control Inter-VLAN multicast replication
Ethernet OAM	EFM OAM	Neighbor discovery Link monitoring Fault notification Remote loopback
QoS features	Traffic classification	Traffic classification based on the combination of the L2 protocol header, IP 5-tuple, outbound interface, and 802.1p priority
	Action	Access control after traffic classification Traffic policing based on traffic classification Re-marking packets based on traffic classifiers Class-based packet queuing Associating traffic classifiers with traffic behaviors
	Queue scheduling	PQ scheduling DRR scheduling PQ+DRR scheduling WRR scheduling PQ+WRR scheduling
	Congestion avoidance	SRED WRED
Configuration and maintenance	Terminal service	Configurations using command lines Error message and help information in English Login through console and Telnet terminals Send function and data communications between terminal users
	File system	File systems Directory and file management File uploading and downloading using FTP and TFTP
	Debugging and maintenance	Unified management over logs, alarms, and debugging information Electronic labels User operation logs Detailed debugging information for network fault diagnosis Network test tools such as traceroute and ping commands Interface mirroring and flow mirroring
	Version upgrade	Device software loading and online software loading BootROM online upgrade In-service patching
Security and management	System security	Different user levels for commands, preventing unauthorized users from accessing AC SSHv2.0 RADIUS and HWTACACS authentication for login users ACL filtering DHCP packet filtering (with the Option 82 field) Defense against control packet attacks Defenses against attacks such as source address spoofing, Land, SYN flood (TCP SYN), Smurf, ping flood (ICMP echo), Teardrop, and Ping of Death attacks
Security and management	Network management	ICMP-based ping and traceroute SNMPv1, SNMPv2c, and SNMPv3 Standard MIB RMON

AP Management Specifications

Feature	Specifications
AP access control	Displays MAC addresses or SNs of APs in the whitelist. Adds a single AP or multiple APs (by specifying a range of MAC addresses or SNs) to the whitelist. Automatically discovering and manually confirming APs. Automatically discovering APs without manually confirming them.
AP region management	Supports three AP region deployment modes: ·Distributed deployment: APs are deployed independently. An AP is equivalent to a region and does not interfere with other APs. APs work at the maximum power and do not perform radio calibration. ·Common deployment: APs are loosely deployed. The transmit power of each radio is less than 50% of the maximum transmit power. ·Centralized deployment: APs are densely deployed. The transmit power of each radio is less than 25% of the maximum transmit power. Specifies the default region to which automatically discovered APs are added.
AP profile management	Specifies the default AP profile that is applied to automatically discovered APs.
AP type management	Manages AP attributes including the number of interfaces, AP types, number of radios, radio types, maximum number of virtual access points (VAPs), maximum number of associated users, and radio gain (for APs deployed indoors). Provides default AP types. Supports user-defined AP types.
Network topology management	Supports LLDP topology detection.

Application Scenarios

The AC6605-26-PWR is connected to an aggregation switch in chain or branched mode.

The AC6605-26-PWR processes both control flows and data flows. Management flows must be transmitted over Control And Provisioning of Wireless Access Points (CAPWAP) tunnels. Data flows can be transmitted over CAPWAP tunnels or not, as required.

The CAPWAP protocol defines how APs communicate with ACs and provides a general encapsulation and transmission mechanism for communication between APs and ACs. CAPWAP defines data tunnels and control tunnels.

Data tunnels encapsulate 802.11 data packets to be sent to the AC.

Control tunnels transmit control flows for remote AP configuration and WLAN management.

Two forwarding modes are available according to whether data flows are transmitted on CAPWAP tunnels:

Direct forwarding: is also called local or distributed forwarding.

Tunnel forwarding: is also called centralized forwarding. It is usually used to control wireless user traffic in a centralized manner.

You can select the chain or branched mode according to networking requirements. On the AC, you can configure direct forwarding for some APs and tunnel forwarding for other APs. In tunnel forwarding mode, all wireless user traffic is aggregated to an AC, which may create a switching bottleneck. Therefore, tunnel forwarding is seldom used on enterprise networks.
