Help CenterFJL-700/1200 Hi-speed Automatic Vacuum Forming Machine
Related Products
-
FJL-610/860BZD-A Single Station Semi-automatic Plastic Vacuum Packing MachineNegotiableMOQ: 1 Set -
FJL-610/860BZD-A Single Station Semi-automatic Plastic Vacuum Packaging MachineNegotiableMOQ: 1 Set
-
FJL-700/1200ZK-B Plstic Tray Vacuum Forming MachingUS$ 21,000 - 23,000MOQ: 1 Set
-
FJL-700/1200ZK-B Fuxinlong Vacuum Forming MachingUS$ 21,000 - 23,000MOQ: 1 Set
-
FJL-700/1200ZK-B Plastic Tray Making MachingUS$ 21,000 - 23,000MOQ: 1 Set
Specifications
Vacuum Forming Machine are suitable for processing those reeling sheets including PP, PS, HIPS, PVC, PET etc.Usage:
The FJL-700/1200ZK Series Vacuum Forming Machine are suitable for processing those reeling sheets including
PP, PS, HIPS, PVC, PET etc. Under various specifications, it can be used for the forming of disposable fast-food containers, instant noodle bowls, western dinner plates, food coverings (such as sugar boxes, cake boxes and
etc), articles of daily use, hardware coverings, children's toys and trays for raising seedlings of rice, vegetables and
other plantations.
Major Construction Features:
1. This machine adopts advanced PLC controlling system; it can automatically finish a series of tasks including
feeding, heating, thermoforming, cooling, drawing off patterns, cutting and stacking.
2. It’s equipped with a feeding device of a precision retarding electric machine, and geared by a double-lined needle-point chain, this machine can achieve both accuracy and stability during high-speed operations; what is more, it is also easy to make quick adjustments so as to make good use of the plastic
sheets to reduce waste.
3. Equipped with a unique divided temperature control system and a precision remote infrared ceramic heater, this
machine can get the most stable and even temperature, and at the same time achieve electricity saving.
4. This machine also possesses some special features: it can be manually pre-started, the switch console can be moved up and down according to needs, it can achieve a delaying vacuum state
or a vacuum state for a second time, and it can be put on patterns for a second time, also it can draw off patterns
through shaking. All these special features can help to accelerate the forming speed and ensure the quality of the
products
5. The major electronic devices and pneumatic components are manufactured abroad,
which can ensure the stability, safety and durability of this machine
Model |
FJL-700/1200ZK-A |
FJL-700/1200ZK-B |
Sheet Width |
510~740mm |
|
Sheet Thickness |
0.1~1.2mm |
|
Forming Length |
700~1200mm |
|
Forming Width |
480~700mm |
|
Max. Forming Depth |
Negative Mould ≤ 180 mm |
|
Positive Mould ≤ 200mm | ||
Used Sheet |
PP, PS, HIPS, PVC,P ET Sheet Roll |
|
Running Speed |
3-12 Moulds/Min |
|
Mode of cutting arrangement. |
Off Mould |
|
|
Heating arrangement |
Top Heating with IR Ceramic Heaters |
Top + Bottom
|
Heating Power |
20KW |
35KW |
Vacuum Ration |
100 m3/h |
|
Air Consumption |
1.2 m3/h |
|
Water Consumption |
0.6 ~ 0.8 m3/h |
|
Power Supply |
380/220V,50Hz, Tri-phase, Four Wire |
|
Overall Dimension |
7.8mX1.4 mX2.2m |
|
Weight |
3.0T |
3.2T |
