Home > Products > Thermoforming Machine > sz-680 Ruian cup making machine
sz-680 Ruian cup making machine
- 10 Set / Sets per Month
- NINGBO
- T/T
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | FUXINLONG | Model Number: | sz-680 |
Product Description
Specifications
1. The sheet feeding & stretching of plug inside of up mould are driven by servomotor.2. control by PLC & touch screen
Main Features:
1)It is mainly used to produce different plastic cups, such as ice cream cups, cold/hot drinking cups, yoghurt
cups, jelly cups, coffee cup, etc. It could also make some regular shape products, such as bowls, dishes, trays, covers/lids, etc with different moulds.
2) The sheet is driven by pin chain and the pin chain is driven by servomotor. The feeding length could be adjusted by parameter setting through touch screen.
3) The stretching of plug inside of up mould is controlled by servomotor.
4) Mould adopts four pillars to fix the mould.
5 It adopts hydraulic system to drive the movement of the mould.
6) Fill oil automatically to lubricate mechanism movement at certain time.
7) Temperature controller modules to control up and down temperature area.
8) It can finish production at one time through sheet feeding, heating, stretching, forming and in-mould cutting.
9) Stable operation and reliable performance, low noise, high quality.
10) Machine frame adopts square bar to make it. Its lifespan will be longer.
11) The movement of heating oven is controlled by touch screen.
12) Waste sheet winder to collect the waste sheet.
Main Technical Parameter:
1. Material Used: PPHIPSPETPVC Sheet Roll
2. Sheet Width: 300-660mm
3. Sheet Thickness: 0.2-2mm
4. Forming Speed: 15-32moulds/min
5. Forming Depth: ≤125(mm)
6. Max. Sheet Roll Dia.: 800mm
7. Max. Forming Area: 650*320(mm)
8. Oil Pump Motor Power: 15KW
9. Approx. Electricity Consumption: 45KW
10. Air Pressure: 0.6-0.8MPa
11. Water consumption: 0.5-1.8m3/h
12. Air consumption: 1.3-1.6m3/min
13. Overall Dimension: 3.15*1.5*2.3(m)
14. Weight: 4200Kg
15. Power Supply: 380V/50HZ, Tri-phase, Four wire
