Help CenterAutomatic FJL-530/760 Air Pressure Plastic Thermoforming Machine
Related Products
-
SZ-680II Plastic Glass/ Box/ Cup Making MachineUS$ 18,000 - 30,000MOQ: 1 Set -
FJL-660SB-B Plastic Cup Thermoforming MachineUS$ 18,500 - 21,000MOQ: 1 Set
-
FJL-660SB-D Plastic Cup Thermoforming MachineNegotiableMOQ: 1 Set
-
FJL-660SB Automatic Plastic Cup Making Machine Price, Thermocol Plate Making MachineUS$ 20,500 - 45,000MOQ: 1 Set
-
FJL-660SB-C Machines for Making Disposable Plates/ Disposable Plate Making Machine/ Foam Plate Making MachineUS$ 21,000 - 243,000MOQ: 1 Set
Specifications
It is suitable to form BOPS,HIPS,PS,PVC, PET and other plastic sheet roll,which can produce various of boxes,trays and so on.
Feature:
FJL-530/760 Automatic Plastic Air-Pressure Thermoforming Machine is a combination of mechanical, electrical and pneumatic components, and the whole system was controlled by a micro PLC, which can be operated in man-interface. It combines the material sending, heating, forming and cutting into one process. It has three operation models. "manual", "semi-automatic"and "automatic".
Usage:
It is suitable to form BOPS HIPSPSPVC and PET plastic sheets etc., which can produce various of boxes dishestraysbowls and lids, such as food boxescake boxesfast-food boxessupermarket traysinjection traysoral liquids trays etc.
Parameter:
1. Forming area: 530x760mm
2. Forming depth: 120mm
3. Sheet thickness range: 0.15-1mm
4. Sheet roller diameter: 710mm
5. Max.Blade Length: 7000mm
6. Ari Consumption:1.6m3/min
7. Water consumption: 0.015m3/min
8. Speed: 600-1500 Times/min
9. Voltage: AC380V
10. Heating plate power: 12kw
14. Max Sheet width: 710mm
15. Weight: 3500kg
16. Dimension(LxWxH)2750x1700x2500(mm)
Over packing size: (L xW x H): 2900 x 1700 x2500mm
