Help CenterFJL-660SB-B Plastic Cup Thermoforming Machine
Related Products
-
FJL-660SB-D Plastic Cup Thermoforming MachineNegotiableMOQ: 1 Set -
FJL-660SB Automatic Plastic Cup Making Machine Price, Thermocol Plate Making MachineUS$ 20,500 - 45,000MOQ: 1 Set
-
FJL-660SB-C Machines for Making Disposable Plates/ Disposable Plate Making Machine/ Foam Plate Making MachineUS$ 21,000 - 243,000MOQ: 1 Set
-
Automatic Machine to Make Disposable Cup, Disposable Cup Making MachineUS$ 20,500 - 45,000MOQ: 1 Set
-
FJL-660SB-C Plastic Cup Production LineUS$ 28,000 - 35,000MOQ: 1 Set
Specifications
Plastic cup thermoforming machine be used for producing disposable plastic vessels,such as cup,tray,lids,dish,plate,box etc.Usage:
FJL-660SB-B Plastic Cup Thermoforming Machine is used to produce disposable water drinking cups, ice-cream cups, disposable cup/bowl for yoghurt, lids, dishes, plates and etc.
Mould photos
Major Construction Features:
FJL-660SB-B Plastic Cup Making Machine is new equipment, which has been developed and produced with many years of machine producing experiences of our company, it uses stable hydraulic system and pneumatic technology to control together, its operation is stable, noise is small, mold locking ability is strong and quality is high. It mainly consists of formed machine, material rack, material receiving machine and screen controlled by electricity.
A)The machine is completely automatic, productive speed is fast. Different products can be produced with different molds.
B) It uses import famous brands of electric and pneumatic fittings, so the operation is stable, quality is reliable and life is long.
C) The design of the mold is advanced and special, heat the thermoplastic plastic flake board and put on the mold, pull the piston, give the pressure to the air, keep the flake board close to the inside of the mold to form, then, cut and automatically blow the product. The structure of the whole machine is compact, one mold has all the functions, like pressure giving, forming, cutting, cooling, and finished product blowing, so the process is short, quality of the finished product is high and matches with national sanitary standard.
Product photos
Main Technical Parameter:
| Model | FJL-660SB-B |
| Max.Forming Area | 650 x 220 mm |
| Approx. Running Speed | 15-30 strokes / min |
| Suitable Sheet Width | 300- 660 mm in rolls. |
| Mode of Cutting Arrangement. | In mould automatic |
| Sheet Thickness Range. | 0.20-2.0 mm |
| Material Used | PP,HIPS,PET,PVC |
| Max.Draw Depth, i.e. Cup Length. |
125 mm |
| Oil Pump Motor Power | 11KW |
| Max. Sheet Roll Diameter. | 800 mm |
| Heating Arrangement | Top + bottom heating with IR Ceramic Heater(104pieces, 650W) |
| Temperature Controller & Thermocouple. | PID K-Type |
| Type of Mould | Multi cavity 1 - 3 row. |
| Approx. Electricity Consumption | 35KW |
| Approximate Dimension | L3400 × W1500 × H2300 (mm) |
| Approximate Weight | 4200Kg |
