KA-30 0.8Mpa Reciprocating Portable Air Compressor

Name: KA-30 0.8Mpa Reciprocating Portable Air Compressor
Brand: kaishan
SKU: 101487747

US$ 700 - 3,000 MOQ: 1 Set

Key Specifications

Type:

Reciprocating

Configuration:

Portable

Power Source:

AC Power

Kaishan General Machinery Co., Ltd. (Beijing)

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjain port ningbo port

Delivery Detail:

Delivery time depends on order quantity.

Type Reciprocating

Configuration Portable

Power Source AC Power

Lubrication Style Oil-less

Mute Yes

Place of Origin Zhejiang, China

Brand Name kaishan

Model Number KA-30

Specifications

suitable to applied in the continuous operation under heavy load for long working time with higher reliability /longer lifespan

This series air compressor widely used in pneumatic lock,pneumatic tool,tire inflation,blowing process,spray paint,san blasting and fluidic element.

adventadge:

1)Special designed is made in heat emission and air flow,which leads to low air-output temp and low possibility of carbon deposit.

2)the piston ring imported from Japan is introduced in designing pistol ring,which is durable and sealable.

3)the core of air filter is made of imported filter paper,which acts well in filter and absorbing noise.

4)Lower noise level, oil free air compressor.

KAISHAN has been specializing in air compressor for over 25 years and has got ISO900:2008 and many quality system certificates.

KA series industrial piston type air compressor technology parameter
NO.	Model	motor power	air delivery	working pressure	overall dimension
NO.	Model	HP/kW	m3/min	MPa(kg/cm2G)	mm×mm×mm
1	KA30	30/22	3	0.8(8)	1900×850×1400
2	KA25	25/18.5	2.5	0.8(8)	1800×800×1370
3	KA20	20/15	2	0.8(8)	1800×800×1300
4	KA15	15/11	1.51	0.8(8)	1640×700×1220
5	KA10	10/7.5	1	0.8(8)	1560×650×1170
6	KA7.5	7.5/5.5	0.67	0.8(8)	1425×560×1050
7	KA5.5	5.5/4	0.52	0.8(8)	1425×560×1050
8	KA4	4/3	0.4	0.8(8)	1310×500×960
9	KA3	3/2.2	0.3	0.8(8)	1310×500×960
10	KAH30	30/22	2.5	1.25(12.5)	1900×800×1400
11	KAH25	25/18.5	2	1.25(12.5)	1800×800×1370
12	KAH20	20/15	1.6	1.25(12.5)	1800×800×1370
13	KAH15	15/11	1.22	1.25(12.5)	1635×670×1320
14	KAH10	10/7.5	0.84	1.25(12.5)	1554×650×1140
15	KAH7.5	7.5/5.5	0.65	1.25(12.5)	1490×580×1120
16	KAH5.5	5.5/4	0.45	1.25(12.5)	1425×560×1050
