KS40-3.0kw,0.4m3/min,0.8Mpa,Suitable for 16 hours of continuous operation KS series reciprocating air compressor

FOB Price

USD $500 - $3,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port tianjain port ningbo port any port of china
Payment Terms:T/T D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Type:	Reciprocating	Configuration:	Portable	Power Source:	AC Power
Lubrication Style:	Lubricated	Mute:	Yes	Place of Origin:	Zhejiang, China
Brand Name:	kaishan	Model Number:	KS40

Product Description

Specifications

Short production and delivery time,suitable continuous operation under heavy load for long working time with higher reliability

KS industrial piston type air compressor

1.exhaust pressure: 0.8-1.25 Mpa
2.displacement: 0.08-2.1 M3 / Min
3.motor power range: 1.1-18.5 Kw

usage

This series air compressor widely used in pneumatic lock,pneumatic tool,tire inflation,blowing process,spray paint,san blasting and fluidic element.

KS series industrial piston type air machine technical parameters
No.	Model	Motor power	air delivery	Max working pressure	overall dimension
		HP/kW	m3/min	MPa(kg/cm2G)	mm×mm×mm
1	KS10	1.5/1.1	0.08	0.8(8)	810×240×800
2	KS15	2.0/1.5	0.12	0.8(8)	860×350×710
3	KS20	3.0/2.2	0.18	0.8(8)	980×370×800
4	KS30	3.0/2.2	0.25	0.8(8)	1000×450×750
5	KS40	4.0/3	0.4	0.8(8)	1500×520×1050
6	KS55	5.5/4	0.55	0.8(8)	1500×520×1050
7	KS75	7.5/5.5	0.75	0.8(8)	1600×570×1110
8	KS100	10/7.5	1	0.8(8)	1650×600×1200
9	KS150	11	1.5	0.8(8)	1850×650×1370
10	KS200	20/15	2	0.8(8)	1850×680×1420
11	KS240	20/15	2.4	0.8(8)	1850×710×1440
11	W327-D1	25/18.5	3.2	0.7(7)	1900×880×1650
12	KSH30	3.0/2.2	0.21	1.25(12.5)	1500×520×1050

13	KSH40	4.0/3	0.3	1.25(12.5)	1500×520×1050

14	KSH55	5.5/4	0.45	1.25(12.5)	1500×520×1050

15	KSH75	7.5/5.5	0.6	1.25(12.5)	1650×600×1200

16	KSH100	10/7.5	0.8	1.25(12.5)	1650×600×1200

17	KSH100D	10/7.5	1.05	1.0(10)	1650×600×1200

17	KSH150	11	1.2	1.25(12.5)	1650×650×1400

17	KSH150D	11	1.6	1.0(10)	1650×700×1400

18	KSH200	20/15	1.7	1.25(12.5)	1850×800×1550

19	KSH240	20/15	2.1	1.25(12.5)	1850×800×1600

adventadge:

1)Special designed is made in heat emission and air flow,which leads to low air-output temp and low possibility of carbon deposit.

2)the piston ring imported from Japan is introduced in designing pistol ring,which is durable and sealable.

3)the core of air filter is made of imported filter paper,which acts well in filter and absorbing noise.

4)Lower noise level, oil free air compressor.

KS series of industrial machine characteristics
Low speed design, operation more quiet, longer life,
Reed valve design, higher efficiency;
Air filter core adopts imported filter paper production, filtration and sound attenuation effect is good, durable;
Electromagnetic switch adopts imported brands, such as: schneider, taian, etc.;
Piston ring USES the Japanese bedding mortar ring, durable, no oil;
Respirator channel using labyrinth structure, ensure that don't emit oil;
The moving parts by precision balance, smooth running, low noise,
Check valve valve core using new composite material, ensure that don't leak;
Fan wheel by zhejiang university patent technology, cooling effect is much better.
Suitable for 16 hours of continuous operation
