TY-350.2R .SF Vertical Injection Molding Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Vertical
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai & Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TY-400DS Vertical Plastic Injection Molding MachineNegotiableMOQ: 1 Set -
TY-700.2R Rotary Table Injection Molding MachineNegotiableMOQ: 1 Set
-
85 Tons of Rotary Table 2 Work Station Molding MachineNegotiableMOQ: 1 Set
-
TY-3R.2C Vertical Injection Moulding MachineNegotiableMOQ: 1 Set
-
TY-.3R.2C Vertical Injection Moulding MachineNegotiableMOQ: 1 Set
Condition
New
Type
Preform Injection
Style
Vertical
Brand Name
TAYU
Model Number
TY-350.2R .SF
Place of Origin
Zhejiang, China
Plastic Type
Thermoplastic
Automatic
Other, semi-auto
Injection Weight
26g
Injection Rate
62cm3/s
Clamping Force
35 tons
Opening Stroke
65 mm
The following materials are suitable for our products:GPPS, HIPS, SAN, ABS,LDPE, HDPE,PP, PPO, PA6, PA66, ACEAL COPOLYMER, CAB, PET, PBT,PC, PMMA, hard PVC, soft PVC,PU, EVA, PSF, Bakelite, BMC.
Vertical-type four-column mould clamping. Vertical-type injection, mould-clamping force of 12 tons to 250 tons, ejection volume of 35g to 1000g, Chinese/English electrical control, screen display, effective, fast and stable hydraulic system, reasonable mechanical structures, convenient operation, suitable for the production of second compacting products such as electric and electronic products.
| Specification | |||
| Model | Units | TY350.2R .SF | |
| Screw Diameter | mm | 18 | |
| Injection Pressure | Kg/cm2 | 3500 | |
| Injection | Theoretical Shot volume | cm3 | 29 |
| System | Max. Shot Weight | g/Oz | 26/0.9 |
| Injection Rate | cm3/sec | 62 | |
| Temperature Control | ZONE | 6 | |
| Material Hoppper Capacity | L | 15 | |
| Clamping Force | T | 35 | |
| Opening Force | T | 5.6 | |
| Calming | Mold Dimensions | mm | 415x250 |
| System | Min Mold Height | mm | 200 |
| Opening Stroke | mm | 300 | |
| Max. Open Daylight | mm | 500 | |
| Ejector Force | T | 2.3 | |
| Ejector stoke | mm | 65 | |
| Slide Plater Size | mm | ||
| Slide Plater Stoke | mm | ||
| Round Set Diamter | mm | φ900 | |
| Hyatraulic | Max. Hydaulic Pressure | Kg/cm2 | 140 |
| electric | Pump Output | L | 240 |
| System | Pump Motor Power | Kw | 15 |
| Barrel Heating Power | Kw | 2.5 | |
| Total Wattage | Kw | 17.5 | |
| Other | Machine Weight | T | 1.7 |
| Machine Dimensions(LxWxH) | mm | 2x1.5x3.2 | |
