Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > TY-400DS Vertical Plastic Injection Molding Machine

TY-400DS Vertical Plastic Injection Molding Machine

Name: TY-400DS Vertical Plastic Injection Molding Machine
Brand: TAYU
SKU: 101471735
Availability: InStock

TY-400DS Vertical Plastic Injection Molding Machine thumbnail-1

TY-400DS Vertical Plastic Injection Molding Machine photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Preform Injection

Style:

Vertical

Contact Supplier Request Quote Chat Now

Hangzhou Tayu Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Preform Injection

Style Vertical

Brand Name TAYU

Model Number TY-400DS

Place of Origin Zhejiang, China

Plastic Type Thermoplastic

Automatic Other, semi-auto

Injection Weight 86g, 109g

Injection Rate 58, 73cm3/s

Clamping Force 40T

Opening Stroke 200mm

The following materials are suitable for our products:GPPS, HIPS, SAN, ABS,LDPE, HDPE,PP, PPO, PA6, PA66, ACEAL COPOLYMER, CAB, PET, PBT,PC, PMMA, hard PVC, soft PVC,PU, EVA, PSF, Bakelite, BMC.

Vertical-type four-column mould clamping, vertical-type injection, mould-clamping force of 40t,

ejection volume of 86g to 109g, Chinese/English electrical control, screen display, effective,

fast and stable hydraulic system, reasonable mechanical structures, convenient operation,

auto(motor) parts, suitable for the production of second compacting products such as electric and

electronic products.

SPECIFICATION

Model		Units	TY-400DS
Injection system	Screw Diameter	mm	32	36
	Injection Pressure	Kg/cm²	1662	1313
	Theoretical Shot volume	cm³	96	122
	Max. Shot Weight(P.S)	g/Oz	86/3.0	109/3.8
	Injection Rate	cm³/sec	58	73
	Temperature Control	ZONE	3
	Material Hopper Capacity	L	20
Clamping system	Clamping Force	T	40
	Opening Force	T	8.3
	Mold dimensions	mm	415x250
	Min Mold Height	mm	150
	Opening Stroke	mm	200
	Max. Open Daylight	mm	350
	Ejector Force	T	1.3
	Ejector stoke	mm	40
Hydraulic electric system	Max. Hydraulic Pressure	Kg/cm²	140
	Pump Output	L	160
	Pump Motor Power	KW	5.5
	Barrel Heating Power	KW	4.1
	Total Wattage	KW	9.6
Other	Slide table Stoke	mm	420
	Round Set Diameter	mm	-
	Machine Weight	T	1.95
	Machine Dimensions(L x W x H)	m	1.9x1.1x2.7
