Help CenterTY-850.2C Vertical Injection Moulding Machine
Related Products
-
TY-850.3R.2C Vertical Injection Moulding MachineNegotiableMOQ: 1 Set -
Double Color Injection MachineNegotiableMOQ: 1 Set
-
TY-1500.2R ROTARY Injection Molding MachineNegotiableMOQ: 1 Set
-
TY-700Z Plunger Plastic Molding Machine/bakelite MachineNegotiableMOQ: 1 Set
-
TY-2100.2R.J Servo Turntable Vertical Injection Molding MachineNegotiableMOQ: 1 Set
1.Vertical clamping, vertical injection structure
2.Two groups of independent injection unit consists of two groups of motor oil pump power and can independent action, stable and reliable, and can do 2 at the same time, reduce the cycle time, increase the capacity; Injection unit parallel arrangement of two groups, according to the requirements of the products, can be independent to set the process parameters, make product quality reach the best state.
| Specification | ||||
| Model | Units | TY850.2C | ||
| A | B | |||
| Injection system | Screw Diameter | mm | 32 | 36 |
| Injection Pressure | Kg/cm2 | 1662 | 1313 | |
| Theoretical Shot volume | cm3 | 96 | 122 | |
| (P.S) Max. Shot Weight | g/Oz | 86/3.0 | 109/3.8 | |
| Injection Rate | cm3/sec | 58 | 72 | |
| Injection Speed | mm/sec | 71 | ||
| Temperature Control | ZONE | 4 | ||
| Material Hoppper Capacity | L | 20 | ||
| Clamping system |
Clamping Force
|
T | 85 | |
|
Opening Force
|
T | 13. | ||
|
Distance Between Tie Bare
|
mm | - | ||
|
Min Mold Height
|
mm | 200 | ||
|
Opening Stroke
|
mm | 200 | ||
|
Max. Open Daylight
|
mm | 400 | ||
|
Ejector Force
|
T | 1.3 | ||
|
Ejector stoke
|
mm | 40 | ||
|
Hydraulic electric syst |
Max. Hydaulic Pressure
|
Kg/cm2 | 140 | |
|
Pump Output
|
L | 480 | ||
|
Pump Motor Power
|
Kw | 11+5.5 | ||
|
Barrel Heating Power
|
Kw | 4.1x2 | ||
|
Total Wattage
|
Kw | 24.7 | ||
|
other
|
Machine Weight
|
T | 4.6 | |
|
Machine Dimensions(LxWxH)
|
m | 2.4x3.1x3.0 | ||
