TY-700DS Double Slide Plate Injection Molding Machine

TY-700DS Double Slide Plate Injection Molding Machine thumbnail-1
TY-700DS Double Slide Plate Injection Molding Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Vertical
Contact Supplier Request Quote Chat Now
Hangzhou Tayu Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Preform Injection
Style Vertical
Brand Name TAYU
Model Number TY-700DS
Plastic Type Thermoplastic
Automatic Other
Clamping Force 70 tons

 TY-700DS Double Slide Plate Injection Molding Machine



     Double Slide Plate Injection Molding Machine



    TY-700DS Double Slide Plate Injection Molding Machine

             Specification
                Model           Units  TY700DS
         Screw Diameter mm φ36 φ42
Injection system       Injection Pressure  Kg/cm2 1723 1266
      Theoretical Shot volume cm3 182 249
      Max. Shot Weight g/Oz 162/5.7 222/7.8
      Injection Rate cm3/sec 87 119
      Injection Speed mm/sec 86
      Temperature Control ZONE 4
      Material Hopper Capacity L 30
Clamping system       Clamping Force  T 70
       Opening Force T 13.5
       Distance Between Tie Bare  mm 500x340
       Min Mold Height  mm 200
       Opening Stroke  mm 250
       Max. Open Daylight  mm 450
       Nozzle Center Height mm
       Nozzle Center Distance  mm
       Ejector Force  T 2.7
       Ejector stroke  mm 75
sliding mode system        Slide Plater Size  mm 1000x495
       Slide Plater Stroke   mm 500
        Round Set Diamter mm
Hydaulic electric system         Max. Hydaulic Pressure  Kg/cm2 140
        Pump Output  L 230
       Pump Motor Power  Kw 7.5
       Barrel Heating Power  Kw 4.5
       Total Wattage  Kw 12
other        Machine Weight      T 2.9
      Machine Dimensions(LxWxH)  m  2.4x1.1x3.1
