DT5802 multimeter
- 0 per Month
- T/T Credit Card
Product Details
Place of Origin: | China | Model Number: | DT5802 | Measuring Current Range: | DCA/ACA:2mA-20A |
Measuring Voltage Range: | DCV:200mV-1000V, ACV:200mV-750V | Measuring Resistance Range: | 200©-200M© | Measuring Capacitance Range: | 2nF-20uF |
Dimensions: | 190*88*34mm |
Packaging Details
Standard export packing or as customers' requests
Product Description
Specifications
DT5802 3 1/2 Digital multimeterDCA/ACA:2mA-20A
DCV:200mV-1000V,ACV:200mV-750V
200-200M(ohm),2nF-20uF...
Auto Power Off.....
DT5802 3 1/2 Digital multimeter
Specification
Function | Range | Accuracy |
DC Voltage | 200mV-1000V | ±(0.5%+1dgt) |
AC Voltage | 200mV-750V | ±(0.8%+3dgt) |
DC Current | 2mA-20A | ±(0.5%+1dgt) |
AC Current | 2mA-20A | ±(1%+3dgt) |
Resistance | 200Ω-200MΩ | ±(0.8%+1dgt) |
Capacitance | 2nF-20µF | ±(2.5%+3dgt) |
Diode Test | Yes | |
Transistor Test | Yes | |
Continuity Buzzer | Yes | |
Auto Power Off | Yes | |
Power Supply | 9V Battery 6F22 | |
Maximum Display | 1999 | |
Product Net Weight | 310g | |
Products Size | 190×88×34mm | |
Standard Accessories | Test Lead, Battery, Manual, Holster |
......We are manufacturer, trader for many years. Other more products or have fyrther enquiry, welcome to contact us.
