JY - SA1600 jumbo paper slitter rewinder , Full automatic paper tube cutting machine

FOB Price

Negotiable / Set

1 Set(Min.Order)

Port ningbo port or shanghai port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Slitting Rewinder
Computerized	Yes	Place of Origin	Zhejiang, China
Brand Name	wzjinyue	Model Number	JY-SA1600
Voltage	380*3V	Power(W)	15 KW
Dimension(LWH)	280030001200 MM	Weight	5000 KGS
Certification	CCIS	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

JY - SA1600 jumbo paper slitter rewinder , Full automatic paper tube cutting machine

Product Description

USE:

Suitable for all kinds of kraft paper, tea paperboard, grass paperboard, calico and art paper cutting

FEATURE:

1. Two blades cutting; thicken blade;

2.The two side of the paper will be smooth after the cutting, without any burring;

3. Tray paper will be tidy with two sides feat;

4. With the computer rectified system and it can rectified automatically.

5. All the operation will be finished on the panel with ease operation;

6. With high capacity, the single machine can be provided for three sets of reel-pipe machine;

7. S.S structure body; beautiful performance;

8. Pneumatic discharge with easy operation

9. Double magnetic powder brake control, and with equally tension

Technical Parameter		Control system
Jumbo roll width	25-1600 mm	PLC controller	Optional
Un-winder diameter	1500 mm	Touch screen	Optional
Re-winder diameter	1400 mm	transducer	Delta
Slitting speed	0-300 m/min	Electrical product	Schneider
Slitting range	20-900 g	Signal part	Omron
Re-winding method	stalk involution	Pneumatic part	AIRTAC
Blade quantity	21 pairs	Driving system
Load paper roll	Pneumatic way	Main motor	7.5 KW
Speed adjust	Transducer	Load paper power	2.2 KW
Power supply	3*380V	Correction motor	Y110 6:1
Mainframe & Weight		Winding reducer	WPA155
Un-winder part	34502100950 mm	Load paper reducer	WPA100
Re-winder part	230028001400mm	Driving way	Connected bearing
Up-blade	105704	Equipped devices
Low-blade	105704	Load paper way	hydraulic way
Weight	5000 KGS	Unload paper way	Pneumatic
Accessories		Auto edge correction	Electric screw correct device
Useful tool	1 set	Counter meters	Automatically counter
Wrench	Hex wrench	Tension correction	Pneumatic adjust
One instruction manual		Brake	Double steam brake adjust

1.OEM service is welcome!

2.We will provide all the details to you during the mass production

3.Customize your mould according to your need

4.Your requirements and complains are highly respected

5.Necessary test and certification can be obtained as you request

6.Our technician and engineers are available to go abroad for machine commissioning and teach how to operate machines.

7.Any spare part of our machines, you can buy from us.

With 15 years OEM experience, we can provide professional solutions for customers. Send your Inquiry Details in the below, click “Send”NOW!
