OEM for SZ800 paper roll slitter rewinder machine
USE:
All kinds of 35-500 grams paper and cloth etc composite materials, especially for papermaking
and Corrugated board boxes factories, the optimal option of cutting equipment.
FEATURE:
1.Imported pneumatic circular knife cutting, high precision cut, convenient operation, paper cutting width cutting knife can be arbitrary regulation. 2. With two separate air expansion shafts, automatic loading and unloading.3. Pneumatic tension automatic control, paper tape re-winder tidy and compact. 4. Feeding materials plate frame adopts automatic promotion function.
Technical Parameter |
Control system |
||
Jumbo roll width |
10-800 mm |
PLC controller |
Delta DVP14SS2 |
Un-winder diameter |
1000 mm |
Touch screen |
MCGS TPC7062 |
Re-winder diameter |
800 mm |
transducer |
YASKAWA |
Slitting speed |
0-300 m/min |
Electrical product |
Schneider |
Slitting range |
35-600 g |
Signal part |
Omron |
Re-winding method |
stalk involution |
Pneumatic part |
AIRTAC |
Blade quantity |
21 pairs |
Driving system |
|
Load paper roll |
Motor driven |
Main motor |
4.0 KW |
Speed adjust |
Transducer |
Load paper power |
2.2 KW |
Power supply |
3*380V |
Correction motor |
Y110 6:1 |
Mainframe & Weight |
Winding reducer |
WPA120 |
|
Un-winder part |
1500*1600*1200 |
Load paper reducer |
WPA100 |
Re-winder part |
1500*1900*1400 |
Driving way |
Connected bearing |
Up-blade |
105*70*4 |
Equipped devices |
|
Low-blade |
105*70*4 |
Load paper way |
Automatically motor driven |
Weight |
2000 KGS |
Auto edge correction |
Electric screw correct device |
Accessories |
Tension correction |
Pneumatic adjust |
|
Useful tool |
1 set |
Brake |
Double steam brake adjust |
Wrench |
Hex wrench |
One instruction manual |
|
1.OEM service is welcome!
2.We will provide all the details to you during the mass production
3.Customize your mould according to your need
4.Your requirements and complains are highly respected
5.Necessary test and certification can be obtained as you request
6.Our technician and engineers are available to go abroad for machine commissioning and teach how to operate machines.
7.Any spare part of our machines, you can buy from us.
With 15 years OEM experience, we can provide professional solutions for customers. Send your Inquiry Details in the below, click “Send”NOW!
