Specifications
Stainless steel cartridge filter vesselFood Grade cartridge filter vessel
Excellent welding and finish
Conson’s stainless steel cartridge filter vessel are all made of food grade 316L (or 304) Stainless steel. With a surface finish mirror polish Ra<0.4um(<20 Ra), Electric Polish (EP) as an option. Applications for stainless steel cartridge filter vessel include winery, brewery, dairy, food and beverage processing, also filtration for pharmaceuticals.
cartridge filter vessel could hold cartridge from 1 round up to 75 round. The housing could be divided into three types.
1. Housing with bottom lifting davit, Handles on the body. (For 3 Round to 12 Round)
2. Housing with up lifting davit, (For housings above 12 Round)
3. Housing with bottom and up lifting davit (For housings above 12 Round, High purity)
| Stainless steel cartridge filter vessel Parameters | |||
| Material | 304SS; 316(L)SS | ||
| Cartridge Length | 10"; 20"; 30"; 40" | ||
| Cartridge Quantiry | 1pcs-75pcs | ||
| Adaptor | 222; 226; DOE | ||
| Inlet&Outlet | 1" to 3" Tri clamp | ||
| Design Pressure | 10 bar (150 Psi) | ||
| Surface Finish | Mirror Polish Ra<0.4um (EP as option) | ||
| Vent&Drain Port | HoseBarb / Triclamp. Or as required | ||
| We also customize filter housing accordingly to customer's requirement | |||
Our standard packing is plywood case,
Shipping method including: Courier (DHL, FEDEX etc), By Airline, By Sea
Price Term including: EXW, FCA, FOB, CIF
Except for producing our standard products, We also have profession engineering term who could design according to your needs.
1. Q: Does your company have any MOQ of your products?
A: No, We do not have MOQ requirement, For small orders we could deliver by courier.
2. Q: Does your company accept no-standard (customized) products?
A: Sure, As soon as you could provide drawings or details.
