Paper Box Maker Machine|Paper Containers Machine
- Qingdao Port/Shanghai Port
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Product Type | Other, paper box machine | |
| Processing Type | Paper Folding Machine | Place of Origin | Henan, China | |
| Brand Name | Weier | Model Number | WE | |
| Voltage | 220V/380V | Power(W) | 4000W | |
| Dimension(L*W*H) | 1400*840*2000mm | Weight | 700kg | |
| Certification | CE | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Paper Box Maker Machine|Paper Containers Machine
Technical Parameters:
Paper lunch box machine is an automatic machine with the advantage of fast speed, easy operation and maintenance. It adopts ceramic hot air (hot air generator) sealing the box 4-cornor, which makes it is available for single PE coated paper and double PE coated paper.
It makes single-case paper lunch box after running the whole procedure of auto paper feeding, heating(hot air, by hot air generator) and forming shape (seal the 4-cornor of the lunch box), auto transfer to the connection.
Easy exchange molds to make different size paper lunch box, take-away box, etc.
Technical Parameters:
Box size | Max forming:160*400*40mm, min forming 100*60*20mm(can be customized) |
Raw material | 200-400g PE/PLA coated paper |
Speed | 55-60pcs/min |
Total power | 220V 50Hz, 4kw or 380V 50Hz, 4kw |
Weight | 700kg |
Packing size | 1400*840*2000mm |
Air supply | Air consumption:0.18-0.25m3/min, 0.45Mpa |
Quality Guarantee Terms:
Quality guarantee term is for one year. Malfunctions which are caused by machine-self and quality will be responsible for our manufacturer. Other malfunctions which are caused by operation mistakes, man-made problems, etc will be responsible for clients-self.
