Specifications
1. After you make the straight straw, then use this flexible straw making machine to make U Shaped straw,2.good price
Automatic Syphon machine
Automatic flexible straw making machine provides new levels of performance for the production of flexible straw. Its a high efficiency machine of making flexible corrugated straw from straight one.
The entire operation, from product in-feed and forming to finished product out-feed, is automatically requiring the operator to add the material only.
The straight straw suppiled in the hopper at the top of machine, are fed one by one into the main drum of the machine, and clamped by two mechanical catches. As the main drum rotates, the straw passes through two rotary dies to receive die-pressed dffect, is then compressed with two catches to form flexible. And delivered to the output conveyor automatically.
The main drum always carries 12 straws in successive and different operations. This development represents a giant step formed for higher production of flexible straws.
1.CONSTITUES
This machine mainly by the shaper,the control box ,the hopper,leaves the material transportation to be composed.
2.CHARACTERISTIC
The struture is compact,the automaticity is high,simplicity of operator.
Revolves steadily,limitless adjustable,the production efficiency is high.
Has the output tally function,can the batch warning.
The frequency conversion control,has the barking function.
Has the breakdown automatic stop function.
Main technological parameter:
Length range190 - 260 mm (We can custom-made according to your request)
Power:1.5kw 380v
Capability:200-250 pcs/min we can custom-made according to your request
Outside dimension:1.5*1.8*1.6m
Weight: 1000kg
