3.7"TFT Handheld Digital Storage Oscilloscope(60MHz)

Name: 3.7"TFT Handheld Digital Storage Oscilloscope(60MHz)
Brand: Kangput
SKU: 100926993
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Kangput

Model Number:

HDS2062M-N

Xiamen KANGPUT Electronics Technology Co., Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Kangput

Model Number HDS2062M-N

3.7"TFT handheld digital storage oscilloscope(60MHz)

Main Features:

Autoscale function

60MHz Bandwidth

up to 250MS/s real time sample rate

2 in 1 (Multimeter function support)

Dual Input Channels

Advanced Trigger Functions

Automatic Measurement

Replaceable Li-ion Battery Back-up

LCD back-light adjustment Support

3.8”TFT panel

Application:
1. Design and Debug
2. Circuit function test
3. Education and technical training

Oscilloscope Specification
Model Name	HDS2062M
Bandwidth	60MHz
Sample Rate ( Real time )	250MS/s
Rise time	≤5.8ns
Display	3.8 Inch color display with TFT panel(320x240 pixels,
Channel	Dual
Record length	Max. 6000 points on each channel
GND reference	Oscilloscope and Multimeter independence
Time base range	5ns/div-100s/div step by 1-2-5
Interval(T)accuracy(full bandwidth)	Single:(1 interval time+100ppm×reading+0.6ns)
Vertical Sensitivity	Average>16:(1 interval time +100ppm×reading+0.4ns)
DC Gain Accuracy	5mV/div~5V/div (at input)
A/D Converter	±5%
Max. Input Voltage	8 bits resolution (2CH simultaneously)
Trigger Type	400V(PK-PK) CAT2
Trigger Mode	Edge, Video
Sampling Mode	Normal, Peak detection, Average
Cursor Measurement	V and T between cursors
Waveform storage	4 waveforms
Automatic Measurement	Vpp,Vavg,RMS,Frequency,Period,Vmax,Vmin,Vtop, Vbase,Width, Overshoot,Preshoot,Risetime,Falltime, +Width,-Width,+Duty, -Duty, Delay A→B , Delay A→B
Waveform math	+,-,×,÷, Inverted
Digital Multimeter Testing	Voltage, Current, Resistance, Capacitance, Diode, Continuity
Multimeter specifications
Input Impedance	10 MΩ
Max input Voltage	AC:00V, DC:400V
Max input Current	AC:20A, DC:20A
General specifications
Interface	USB Data Cable (Transfer waveform data to a PC)
Power	Supply:100V~240V AC,50/60Hz DC input: 8.5VDC, 1500mA Battery: 6 hours
Dimension	180mm x 113mm x 40mm
Weight	645g
