1ch network video cctv server,with video analytics function

Model

BE-IVS100D

Channels

Number of Intelligent Video Analysis Channels

1

Analog Video Input

TV Standard

Composite 1Vp-p – NTSC or PAL

Physical Connector

1x BNC 75Ω

Analog Video Output

TV Standard

Composite 1Vp-p – NTSC or PAL

Physical Connector

1x BNC 75Ω

Digital Video Output

IP Video Streaming

MPEG-4 SP and M-JPEG, Two separate, independent and configurable video streams

Max Resolution per Channel

4CIF

Frame Rate

Up to Full Frame Rate

Bit Rate

CBR (128Kbps – 4Mbps), VBR

Network

Ethernet (IEEE 802.3/802.3U)

2x RJ-45 Interface

Services and Protocols

TCP/IP, UDP/IP, HTTP, SMTP, DHCP, DNS, SNTP

Video Streaming

RTP/RTSP

Alarms/Commands

TCP/IP

I/O Interface

Serial (one interface per input for PTZ camera control)

2x RS-232+1x RS-485

IN - Alarm Input

4 x Alarm inputs (from Dry Contacts)

OUT - Relay Output

2x Relay Output (rated load 1A@30VDC)

Power Source

Voltage

12VDC

Power Consumption

8W

Physical Dimensions

Dimensions (mm)

189 x 36 x 164 mm (WxHxD)

Dimensions (inches)

7 7/16" x 1 13/32" x 6 7/16" (WxHxD)

Mounting

Shelf Mount

Environmental Specifications

Operating Temperature

0° to 50° C

Operating Humidity

5% to 95% (Non-Condensing)

Certifications

Safety

CE
