Intelligent Traffic Solutions With Video Analysis Function
- shenzhen
- Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | BELLSENT | |
| Model Number | BE-IVS1 |
Product Description
The BE-IVS 1 is intelligent traffic solutions with video analysis function.
1.Easy to install, sets up in minutes
2.Single channel video encoder, embedded with Bellsent's DSP-based field-proven analytics,
3.Converts any analog CCTV surveillance camera (B/W, color, thermal, and infrared) to networked MPEG-4 CIF-quality video, streaming at full frame rate
4.Detection rate 99%,false alarm rate is less 1/day.
5.Detection types:Regional Entrance Detection,Tripwire Crossing Detection;Fence Trespassing Detection;Anomaly Detection.
full Specifications:
Channels | |
Number of Intelligent Video Analysis Channels | 1 |
Analog Video Input | |
TV Standard | Composite 1Vp-p – PAL |
Physical Connector | 1x BNC 75Ω |
Analog Video Output | |
TV Standard | Composite 1Vp-p – PAL |
Physical Connector | 1x BNC 75Ω |
Digital Video Output | |
IP Video Streaming | MPEG-4 SP, M-JPEG |
Max Resolution per Channel | CIF |
Frame Rate | Up to Full Frame Rate |
Bit Rate | CBR (128Kbps – 4Mbps), VBR |
Network | |
Ethernet (IEEE 802.3/802.3U) | 1x Ethernet RJ-45 Interface |
Services and Protocols | TCP/IP, UDP/IP, HTTP, SMTP, DHCP, DNS, SNTP |
Video Streaming | RTP/RTSP |
Alarms/Commands | TCP/IP |
I/O Interface | |
IN - Alarm Input | 1 x Alarm inputs (from Dry Contacts) |
OUT - Relay Output | 1x Relay Output (rated load 1A@30VDC) |
Power Source | |
Voltage | 12VDC |
Power over Ethernet (PoE) | Supported (IEEE 802.3af) |
Power Consumption | 5W |
Physical Dimensions | |
Dimensions (mm) | 88 x 26 x 130 mm (WxHxD) |
Dimensions (inches) | 3 7/16" x1" x 5 3/32" (WxHxD) |
Mounting | Camera Housing/Shelf |
Environmental Specifications | |
Operating Temperature | 0° to 50° C |
Operating Humidity | 5% to 95% (Non-Condensing) |
Certifications | |
Safety | CE |
