sanitary napkin disposal machine
sanitary napkin disposal machine description
Double cutters, double molds and double conductors in one machine, it can produce products with 2 lengths
1- The machine is specially designed for making ladies panty liner (pad) product
2- Air laid paper or cotton core can be used as absorbent material.
3- The surface material can be used non-woven fabric or aperture film.
4- The product size and embossing pattern can be changed by changing cutting tools and gear box.
5- Phase adjusting units are used in the key sections of the equipment, so it can be adjusted during production without stopping the machine.
6- Tri-folding packing type can be ordered by customer.
7- It can be equipped with PLC control system, touching screen according to customers` demand.
8- This machine has the features of high automation, compact structure, convenient operation and easy maintenance.
sanitary napkin disposal machine main parameters
Designed Speed |
450pcs/min |
Stable Production Speed |
200-250pcs/min |
Production Line Center Distance |
300mm(the distance from the material center line to the rack-mounted panel) |
Distribution of Raw Material |
top(surface)-absorption layer bottom-cloth like non-woven |
The Deviation of Products Weight |
±1.5g |
Rate of Finished Products |
≥97% (not including rejected baby diapers at the glue applicator, splicing and jointing material stations) |
Production Machine Efficiency |
≥85% |
Power Supply |
380V 50HZ |
Power Consumption |
95KW (reference)(not including the glue applicator station and the air compressor) |
Electric Supply |
380V ± 5%,50HZ, (3 phase, for wire plus ground) |
Compressed Air Supply Pressure |
0.6-0.8Mpa (air supplier provided by buyer) |
Overall Machine Dimensions(Stacker excluded) |
21 x 1.8 x 2.8m weight 20 metric tons |
Equipment Process Flow |
to be defined by customer |
sanitary napkin disposal machine advantage
1. Automatic/Full-servo/ Semi-servo system with less worker required.
2. All machining parts are CNC made by our own factory - Quality guaranteed with low repair rate make you a stable production.
3. Applied dumbbell device to the Cotton forming system to prevent bandy legs caused, add an extra selling points for your product.
4. Remote assistance dealing with software problem to give you the efficient after-sale service with no production delayed.
5-.Professional team with 17 years experience, available to various type & appropriate scheme for different countries(Asia,Mid-east,Russia,India,South Africa etc).
sanitary napkin disposal machine function & assemble Parts:
1.Common and ultra thin fluff pulp sanitary towels can be produced.
2.Dust free paper ultra-thin sanitary tomels can be made.
3.Full Pulp is spread through mould-wheel and wrapped and formed with liner of high wet stengtg paper.
4.Interrupted or adjustable spraying of S.A.P can be selected.
5.Independent packing with sealing device, which is easy to be torn out.
If requested, a-3-piece type solid shield apron and blue core piece or flow conducting short cut and dotting device can be supplied.
Staker can be provided as requested by clients.
sanitary napkin disposal machine Structure & Character:
1. The main drive is achieved by connecting a NO.45 hardened and tempered steel shaft ,a universal joint clutch and a right angle gear box.
2.The components are driven by synchronous belt and gears.
3. The main pressing and cutting roller are driven by a universal joint clutch and it is esy to operate with the service life of cutting tools ensured.
sanitary napkin disposal machine sample
packaging and shipping
