rotary drum dryer for fertilizer
Descriptions of rotary dryer:
Rotary Drum Dryer adopts the means of Drum marginal transmission, flange connection, direct heat transfer. It is the main equipment in compound fertilizer production, and used for drying granulated fertilizer or raw material. It can make full use of the energy and get best drying results.
The materials to be dried flows inside rotary dryer from a feeding chute, and pushed afterward by screw flight. The rotary dryer is intalled at 3-5 degree gardient. The dried materials moves to discharge side at itself gravity and the dryer rotation. When materials inside rotary dryer, it is lifted by lifting flight, so that it can touch the hot air sufficiently and evenly.
Main features of rotary dryer:
1) Rotary drier/dryer with professional design
2) Low energy consumption
3) Long life span; Simple structure
4) Low cost and high output
5) Automatic operation
6) High capacity and efficiency
working principle of rotary dryer:
Rotary Drier mainly consists of drum cylinder ,lifter blade, transmission device, supportive device and sealing ring, etc.The heat sources of rotary dryer is from the combustion stove, and is adopts down-flow heating methods. When the materials enter into the body from the feeding device, it will be pushed back by the lifter board. As the rotary dryer is in an inclined position, the materials will be down to the lower end under the influence of gravity and rotation, but the raising board will be threw to the upper end for scattering. This procession makes the material well-distributed in the body, and then ensure the heat exchange with the heat wind. After repeated cycle with this proces, the moisture content will be dried.
Advantages of rotary dryer:
1.rotary dryer use telescope-feed structure, dry the material quickly
2.Simple design, Self-insulation, improve the heat efficiency to exceed 80%
3.Structure delicate, stable operation
4.Good drying performance, coal consumtion<8kg when drying 1t material
5.The fuel can be coal, oil, natural gas etc, dry mass,granule and powder material
6.Reduce land area for 50%, power consumption saved 60%
7.Finished product moisture can be adjusted depends on requirement of client
8.Lower outlet tempreture, longer dust removal using life
9.Drive by tug not gear and pinion
10.Finished product tempreture lower than 60'C , packing can be done continuously.
