Buchi Spray Dryer

buchi spray dryer

Descriptions of buchi spray dryer:

  The spray drying is the technology which is widely used in the liquid technology shaping and in the drying industry. The drying technology is most suitable for producing the powder or particle solid products from the materials, such as: Solution, emulsion. So when the particle size and distribution of the final products, their residual water contents, the stacking density and the particle shape must meet the precision standard, the spray drying is one of the most perfect technologies.

Features

Key Features of buchi spray dryer:

 At a high speed of drying, after the spraying of the material liquid, the surface area of the material will be increased greatly. In the hot-air flow, 95%~98% of water can be evaporated at a moment. The time of completing the drying needs only several seconds.
 This is especially suitable for drying the heat sensitive materials. Its final products own the good uniformity, mobility, dissolving capacity. And the final products are high in their purity and good in their quality. The production procedures are simple and the operation and control are easy. The liquid with the moisture contents 40~60% (for special materials, the contents may reach 90%.) can be dried into the powder or particle products once a time. After the drying, there is no need for smashing and sorting, so as to reduce the operation procedures in the production and to enhance the product purity. The product particle diameters, looseness and water contents can be adjusted through changing the operation condition in a certain scope. It is very convenient to carry out the control and management.

 Advantages of buchi spray dryer:

1. Fast drying speed. Liquid materials after atomization will increase its surface area largely and can be evaporated its moisture 65% to 98% instantly in the hot air flow so as to finish drying within 5 to 15 seconds.It is specially suitable for drying of heat sensitive materials.
2.Dried products have even granule, good flow ability and solubility, high purity and good quality.
3.Simple and stable operation,easy adjustment and control as well as automation.
4.Simplifying process of production,superior and sanitary operation environment,and flying dust can be avoided during the drying process.

Principle of buchi spray dryer:

   After the filtering and heating, the air enters into the air distributor from the top of the drier. The hot air enters into the drying room in the spiral form and uniformly. By passing through the high-speed centrifugal spray on the top of the tower, the material liquid will rotate and be sprayed into the extremely fine mist liquid beads. Through the very short time of contacting the heat air, the materials can be dried into the final products. The final products will be discharged continuously from the bottom of the drying tower and from the whirling separator. Finally the waste gas will be discharged from blower.
