High quality dongfeng tractors
dongfeng tractors specifications
walking tractor is dual-function product that can be operated as the towing machine as well as driving machine. They have small and compact structure, light weight, long service life, reliable performance, easy operation and good running ability, also they are be assemble a seating equipment for driver.
a. Suitable for use in paddy fields,dry fields,orchards,vegetable gardens and hilly lands with a little inclination
b. Used for ploughing, rototilling,harrowing in paddy fields, Harvesting, frilling, ditching,and transportation, if suitable farm implements or accessories are attached
c. It can also be extensively used as a stationary power source for small scale drainage and irrigation,sprinkling,grain threshing, cotton ginning,flour milling, and fodder cutting
Model |
15L/SL/KL/EL |
||
Structureweight |
without rotavator |
Kg |
360/363/378/384 |
with rotavator |
465/468/488/494 |
||
Working Weight (with rotavator) |
kg |
505/508/523/529 |
|
Turning speed of rototilling shaft |
rpm |
188 |
|
Overall dimensions (L×W×H) |
mm |
2680×960×1250 |
|
Number of blades |
PCS |
18 |
|
Rototilling width |
mm |
600 |
|
Type of tractor |
Single axle,dual-purpose for both tractor &drive |
||
Travelingspeed |
Forward |
km/h |
1.4, 2.5, 4.1, 5.3, 9.4, 15.3 |
Reverse |
1.1, 3.8 |
||
Tire Size |
mm |
6.00-12 |
|
Wheel track |
mm |
800,740,640,580(normally use 800) |
|
Min.ground clearance |
mm |
185 |
|
Min.turning radius |
m |
0.9(with no rotavator) |
|
Model ofengine |
S1100A2N |
||
Type of engine |
Horizontal 4-stroke |
||
Bore×stroke |
mm |
100×115 |
|
Total displacement |
L |
0.903 |
|
Compression ratio |
19.5:1 |
||
Turing speed of crankshaft |
rpm |
2000 |
|
1-hour rated output |
kW/hp |
10.50/14.30 |
|
12-hour rated output |
kW/hp |
9.8/13.33 |
|
Specific fuel consumption |
g/kW.h |
257 |
|
Specific lube oil consumption |
g/kW.h |
≤2.04 |
|
Cooling mode |
Condenser(Radiator) |
||
dongfeng tractors advantage
1. Beautiful outer appearance, large capacity fuel tank, the engine works longer
2.Single balance, engines work more stable
3. The specific fuel is low, the engines work more economics
4.Excellent start ability, easy to start
5. Oil bath air-filter makes the engine more suitable to the bad circumstance
dongfeng tractors main features
1)small garden tractor is small and light with low oil consumption, high efficiency and good stability.
2)Easy to operate and suitable for working in the narrow acrid land, paddy field, orchard and vegetable greenhouse.
3)According to different demands of the users, also can used for rotary planting, shallow & deep plowing, transplanting in the paddy field, loosening the soil, atomization, watering & dewatering, sowing and exploring more lands when corresponding equipments or tool are assembled
4)DF model tractor is small and light with low oil consumption, high efficiency and good stability.
5)Easy to operate and suitable for working in the narrow acrid land, paddy field, orchard and vegetable greenhouse.
6)According to different demands of the users, also can used for rotary planting, shallow & deep plowing, transplanting in the paddy field, loosening the soil, atomization, watering & dewatering, sowing and exploring more lands when corresponding equipments or tool are assembled..
dongfeng tractors characteristics
1.This walking tractor uses traction power as well as driven power.
2.It has compact structure, reliable and durable performance, flexible operation, large power, light weight, good trafficability characteristic, and passenger accommodation.
3.It can be applied to the cultivation in paddy field, dry farm, orchard, vegetable garden, and hills.
4.It can also be equipped with some agricultural implements and accessories to be used for ploughing, rotary tillage, harrowing, ditching, sowing, reaping, transportation, and other works.
5.It can be used as the power of drainage-irrigation, sprinkling irrigation, threshing, milling, feed processing, and other stationary work.
6. Models: A with gear box, B with dual variable speed rotary cultivator, C with 7-hole transmission case, E with two-in-one seat, H with main drive speed increase, H2 with drive chain case speed increase, and T with 6.50-16 big tire.
dongfeng tractors product detail
a. Tractorsurface is treated by three layers as priming paint, surface paint and shining paint for better erosion resistance use reinforced transmission case for firmer structure
b. Hang frame and wheel rim adopt nodular cast iron materials for casting, which is abrasion-resist and impact-resist with longer life span equip with special and durable brand tyres
c. All gears adopt national brand gears with abrasion-resistance, lower noise and more reliable quality
d. Manipulating shaft such as gearlever etc should be plating treated twice for anti-abrasion and anti-erosion and durable usage
dongfeng tractors picture
dongfeng tractors working show
packaging and shipping
