P12 Background Rental Outdoor Stage Led Screen

Name: P12 Background Rental Outdoor Stage Led Screen
Brand: SkyMax Display
SKU: 100872519

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

SkyMax Display

Model Number:

SM-P12 SMD LED Screen Series

Zhongshan SkyMax Display Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Zhongshan;Guangzhou Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name SkyMax Display

Model Number SM-P12 SMD LED Screen Series

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels Other, 12mm

Specifications

>Used USA ASM Machines
>Pictures and colors are not distorted
>Can repair each LED Lamp,and low cost
>Seamless splicing

number	Item name	Parameter and index
unit module
1	LED encapsulation mode	3-in-1 SMD5050
2	Horizontal axis	120°
3	Vertical axis	120°
4	Pixel composition	1R1G1B
5	Pixel pitch	12mm
6	Scan method	1/4
7	Drive method	Constant current
8	Module resolution	16×16 pixels
9	Module dimensions	192mm×192mm
10	Module type	incorporated lamp and drive
11	Module working voltage	+5V
12	Module average power	9W
13	Module maximum power	36W
14	Module shell material	PC
15	Module mask material	PC
unit cabinet
1	Module layout	6×4 pieces
2	Cabinet resolution	96×96 pixels
3	Cabinet dimension	1152mm×1152mm
4	Cabinet material	steel/aluminum alloy
5	Cabinet color	black/gray
6	Protection grade (front/back)	IP65/IP54
Entire screen
1	Application environment	outdoor
2	Brightness	>7000 cd/m²
3	White balance coordinates	X=0.29,Y=0.31
4	contrast	64000:1
5	Color temperature	8000K
6	Pixel density	1000pixels/m²
7	Average consumption	297 W/m²
8	Maximum consumption	1187 W/m²
9	Power source	AC220V/50HZ or AC110V/60HZ
10	Operating temperature	-20°c --+50°c
11	Operating humidity	10%-90%
12	Storage humidity	-30°c -+50°c
13	Refresh frame rate	60Hz
14	Refresh rate	480Hz
15	Viewing distance	12-120m
16	grayscale/color	16.7M
17	Brightness adjustment	100 manual levels /100 auto levels/100 timing
18	Control method	synchronous with the computer display
19	Data transfer range	Network; cable:100m
20	Computer operating system	WINDOWS(98, 2000,XP,Vista,7)
21	Longevity	≥100000 hours
22	Certification	UL/CE/CCC
