Stage Background 6mm Rental LED Full Color Display

Name: Stage Background 6mm Rental LED Full Color Display
Brand: SkyMax Display
SKU: 100872591

Negotiable MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

SkyMax Display

Model Number:

SM- Rental led display Series

Zhongshan SkyMax Display Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Zhongshan; Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name SkyMax Display

Model Number SM- Rental led display Series

Usage Indoor

Tube Chip Color Full Color

Display Function Video

Pixels Other, 6mm

Specifications

>Light weight;Thin cabinet
>Flat screen
>Quick dismounting
>Low release heat
>Full compatible

Parameters of P6

NO	Item	parameter
module
1	LED encapsulation mode		SMD3528 surface mounted
2	Horizontal axis		120°
3	Vertical axis		120°
4	Pixel composition		1R1G1B
5	Pixel pitch		6mm
6	Scan method		1/10
7	Drive method		Constant current
8	Module resolution		40×40dots
9	Module size		240mm×240mm
10	Module type		Integration of lamp and drive board
11	Module working voltage		+5V
12	Module average consumption		40W
13	module maximum consumption		10W
14	module shell material		PC
15	module mask material		PC
cabinet
1	Module layout		2×2 pieces
2	Resolution		80×80 dots
3	Cabinet maximum consumption		200W
4	Cabinet average consumption		50W
5	Cabinet dimension		480mm×480mm
6	Cabinet material
7	Cabinet color		black/grey
8
screen
1	Application environment		indoor
2	brightness		>2000cd /m²
3	White balance		X=0.29,Y=0.31
4	contrast		64000:1
5	Color Temperature		8000K
6	density		27777 (dot/m²)
7	Average power consumption		217 (W/M²)
8	Maximum power consumption		868 (W/M²)
9	Power supply mode		AC220V/50HZ~AC110V/60HZ
10	Operating temperature		-20°C to +50°C
11	Operating humidity		10%~90%
12	Storage temperature		-30°C to +70°C
13	Refresh frame rate		60Hz
14	Refresh rate		480Hz
15	Viewing distance		6-100m
16	Grey level/color		16.7M
17	Brightness adjustment mode		Software 100level/ automatic 100level
18	Control manner		Synchronous with the computer display
19	Distance of signal transmission		Net cable 100m
20	Computer operating system		WINDOWS(98,2000,XP,Vista,7)
21	Video signal		VGA,DVI,RF,S-Video,RGB,RGBHV, YUV,YC,COMPOSITION etc
22	MTBF		≥10000hours
23	longevity		≥100000hours
24	certificate		UL/CE/CCC
