waterproof 12volt brushless fan
- 1000000 Piece / Pieces per Month
- shenzhen
- T/T Credit Card
Product Details
Electric Current Type: | DC | Mounting: | Free Standing | Blade Material: | Plastic |
Place of Origin: | Guangdong, China | Brand Name: | SON TIMES | Model Number: | ST6025HS |
Voltage: | 12V/24V | Power: | 1.44-2.64W | Air Volume: | 50-75CFM |
Speed: | 3500-4500RPM | Certification: | CE |
Product Description
Specifications
1. 12v brushless fan2.size:60*60*25mm
3.sleeve,ball bearing
4.rated voltage:12v/24v
5.low noise,large airflow
waterproof 12v brushless fan
Frame size(mm) 60*60*25mm Bearing type ball bearing/sleeve Rated voltage 12/24v Rated speed 3500-4500RPM Max air flow 50-75CFM Max pressure 0.15-0.26inch-H2O Max noise 29-31dBA Functions by impedance,FG Safety approvals CE ROHS Dielectric Strength 5mA max at 1500VAC for 1 min between lead wire and frame Insulation resistance 100M ohm between lead wire and frame(DC 500V) Life expectancy(ball bearing) 70000hrs min at 40 degree C/L10 relative humidity 65%+/-20% Life expectancy(hypro bearing) >40000hrs min at 40 degree C/L10 relative humidity 65%+/-20% Operation temperature -10~80 degree C(+14~176 degree F) Storge temperature -40~75 degree C(-40~167 degree F) Protection Motor protection and polarity protection Lead wire UL1571 AWG26,28; UL1007 AWG26,28; UL1061 AWG30 fan blade material Black PBT (UL94V-0) glass filled frame material PBT Weight 56g
